Battery Installation - Swann Motion Alert Sensor Schnellstartanleitung

1 Using the tab at the bottom, lift off the sensor cover.
2 Insert the supplied two AAA batteries into the battery compartment according to the polarity
markings (+ and -) shown. Pairing mode will automatically activate on the sensor for 3 minutes
when batteries are inserted. The sensor status light will blink blue slowly during pairing mode.
If you have downloaded the Swann Security app on your mobile device (see page 4), you can
proceed to the pairing process (see page 5).
Note: Pairing mode on the sensor can be activated at any time by re-inserting the batteries.
3 After you have paired the sensor, snap the cover back in place.
4 Should you need to replace the batteries in the future, there is no need to re-pair the sensor.
Simply wait for pairing mode to timeout (3 minutes), after which the sensor will automatically
reconnect to the previously configured Wi-Fi network.

BATTERY INSTALLATION
