Window Seal Kit for
AC Unit
Art.no. 36-7983
Please read the entire instruction manual before using the pro-
duct and then save it for future reference. We reserve the right
for any errors in text or images and any necessary changes
made to technical data. If you have any questions concerning
technical problems please contact our Customer Services.
Installation
• You can attach the window sealing kit in different ways
depending on the construction and design of your windows.
• The following assembly instruction is an example.
1. Open the window and clean the surface where the self-
adhesive hook-and-loop fastener tape shall be attached.
The surface must be completely free from dirt, grease and
dust.
2. Attach the hook-and-loop fastener to the window sash and
window frame. Never attach the hook-and-loop fastener to
the sealing strip on the window frame or sash.
UNITED KINGDOM • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk
postal Clas Ohlson Ltd, Aquilla House (First floor), 1 Becketts Wharf, Lower Teddington Road, Hampton Wick, Kingston Upon Thames, KT1 4ER
3. Attach the kit on the hook-and-loop fastener. Start in the
middle of the window using the middle of the kit. The zip
is not centered, attach the thin part to the window sash as
shown in the picture.
4. Open the zip and insert your exhaust air hose, which can
look different depending on the type of AC you have. Pull
the zip around the hose.
Responsible disposal
The product should be disposed of in accordance with local
regulations. If you are unsure how to proceed, contact your
local council.
Specifications
A
B
40°
C
A + B + C = max. 400 cm
