MOVE IT DESK BRACKET
MOUNTING AND SAFETY INSTRUCTIONS
Box contents
GB
1x Desk mounting plate
1x Bracket holder
1x Bracket
4x Spare mounting kit M4x9 -TESA BK 177-2
4x Rip-Lock lock washer M4
3x Rip-Lock lock washer M6
3x Hexagon socket head screw - M6 x 16
4x Cap nut DIN 1587 - M4
1x Drilling template - TESAprod. code BK43-2
1
Mounting instructions
1. The desk bracket must be mounted exactly as described in the manufacturer's instructions.
An incorrectly mounted bracket can become a safety hazard.
2. Before mounting, check that there are no electrical supply lines or cables connected to
electrical devices at the intended mounting site.
3. The desk bracket is only suitable for mounting on flat, even surfaces.
4. If possible, use the enclosed adhesive mounting system.
5. The front edge of the metal bracket with Office Box must be mounted flush with the front edge
of the table. Avoid protruding, as this can cause damage.
6. To find the best mounting position: hold the mounting bridge (desk mounting plate) in place in
the intended mounting position. If there is nothing that could obstruct it there, loosely place
the enclosed self-adhesive pads in the screw holes on the mounting bridge (desk mounting
plate). Remove the backing from the adhesive positioning rings and press the mounting bridge
firmly in place in the chosen position. Then pull off the mounting bridge from the adhesive
adapters. For the next steps, please follow the additional instructions for the TESA self-adhe-
sive adapters. Allow 24 hours for drying. After this, the SIGEL Move it desk bracket
can be mounted.
7. The desk bracket should be mounted by a qualified person.
Each desk bracket can hold up to 16 kg including office boxes.
SIGEL GmbH | 86690 Mertingen | Germany | www.sigel-office.com
