BT Samba Bedienungsanleitung

BT Speaker „Samba"
User Manual
Package Contents
• Bluetooth ® Speaker Samba
• Micro-USB charging cable
• 3,5 mm Audio cable
• User Manual
If any of the above pieces is missing, please pack the product again and bring it back
to your dealer.
Overview
1. Speaker
2. Previous track / Vol-
3. Multifunction Button
4. Start- Stop Musik
5. Next track / Vol+
6. ON/OFF switch LED
7. Micro-USB Charging port
8. 3,5 mm Audio Line-In
9. Status LED
1 2 3 4 5
Getting started
Charging the battery
Samba is equipped with an internal rechargeable lithium-Ion battery. Connect the Micro USB cable
with the micro USB charging port (7) of the Samba. The cable can be connected to a computer or
a standard USB power adapter. The red LED of Samba lights up while charging.
The normal charging time is 2-3 hours. The red LED turns off when fully charged. The cable can
be disconnected.
Note: Charge Samba for at least 2.5 hours before initial use.
Switching On /Off
Switch on: When powered off, switch the button (6) to the „ON" position.
Switch off: Switch the button (6) to the "OFF" position.
Pairing
Samba must be paired with a Bluetooth device before use.
®
This is a two part process; one part is carried out on the Speaker and the other is carried out on
the other Bluetooth device.
®
Note: Please note that different mobile phones may require different pairing methods.
1. Make sure that Samba is powered off. Set the power switch (6) to the „ON" position.
The pairing mode will start.
2. Use your mobile phone, computer or another Bluetooth
Bluetooth ® audio devices.
3. The Bluetooth device should indicate that it has found „Samba".
®
4. Confirm pairing with Samba. Enter „0000" if you are asked for a pairing code.
If you are unsure about the pairing procedure of your Bluetooth
device manual.
If using a Bluetooth ® transmitter without display, set it to pairing mode and wait a few seconds
until the connection with Samba is established.
Note: If the connection is lost or the transmitter is temporarily disconnected, Samba automatically
tries to restore the connection. If the connection cannot be restored after 3 seconds, try again by
pressing the multifunction button (3) for two seconds.
Music playback
Music playback via Bluetooth ®
Start music playback on the Bluetooth source which is paired with the Samba. The music is
®
transferred to the Samba. Stop the music playback on the Bluetooth
streaming.
Note: The device must support the A2DP profile for music streaming. Redial is deactivated during
music playback.
Music control
To play or stop music playback, briefly press the Start/Stop button (4).
To skip to the previous track, press the volume - button (2).
To skip to the next track, press the volume + button (5).
Playback through Line-In
1. Connect the music playing device with the included line-in audio cable to the line-in socket (8)
of Samba.
2. In the off state, switch the power button (6) to the „ON" position.
Briefl y press the mode button (3) to enter AUX mode.
3. The music will be now passed through the Samba speaker.
Note: The buttons have no function when using the wired connection. Use the audio source to
control the music.
6 7 8
9
transmitter in order to search for
®
® device, please check your
® source to interrupt the
Hands-free features
With its built-in microphone and intelligent noise reduction mechanism, Samba is perfectly suited
for use as a hands-free phone.
Note: High volume can cause acoustic feedback from the microphone. This leads to echo on the
caller side, but not on the speaker phone side.
Answer / Ending /Reject calls
To answer an incoming call, briefly press the multifunction button (3).
To end a call, press and hold the multifunction button (3) for 2 seconds.
To reject an incoming call, press and hold the multifunction button (3) for 2 seconds.
Redial
In Bluetooth mode, press the multifunction button (3) twice.
The phone will redial the last outgoing number.
Adjusting the Volume
Press and hold the volume + button (5) to increase the volume.
Press and hold the volume - button (2) to decrease the volume.
Technical Data
• BT V 4.2
• Operating range: Up to 10m
• Profi le: Hands free, Headset, A2DP/ AVRCP
• BT Frequency: 2.402-2.480GHZ, 2.4G
• 3,5 mm audio line-in
• Speaker: 2 x 5 Watts + passive speaker
• Power Input: 5V DC
• Built-in Microphone
• Status LED: Blue/Red
• Micro USB Charging port
• Rechargeable 1200 mAh Lithium-Ion Battery
• Operation time: 2-4 hrs.
• Dimensions: 184 x 82 x 53 cm
• Weight: 384 g
Registration and Safety
Certification/General Information
We hereby declare, that this device carries the CE mark in accordance with the regulations and
standards. It conforms with the fundamental requirements of the RED 2014/53/EC, EMC
directive 2014/30/EC as well as the Low Voltage Directive 2014/35/EC.
Note on environmental protection:
After the implementation of the European Directive 2012/19/EC in the national legal
system, the following applies: Electrical and electronic devices may not be disposed of
with domestic waste. Consumers are obliged by law to return electrical and electronic
devices at the end of their service lives to the public collecting points set up for this
purpose or point of sale. Details of this are defined by the national law of the respective country.
This symbol on the product, the instruction manual or the package indicates that a product is sub-
ject to these regulations. By recycling, re-using the materials or other forms of utilising old devices,
you are making an important contribution to protecting our environment.
Technical specifications and other data could be made without prior notice. 05_2017
GB
