Infocrank navi2coach Schnellstartanleitung Seite 2

FITTING
1
Option A
Option B
INSERT THE BATTERY
2
BASIC ADJUSTMENTS
4
Switch on the navi2coach by pressing and holding the
POWER-button, for 2 seconds. When switched on for the first
time the navi2coach takes you through the most important
basic settings and allows you to pair optional ANT+ sensors
with the device.
Fit and switch on your sensors at the same time as switching
on the navi2coach so that you can pair them straight away.
You can access basic adjustments at any time in the main
menu Settings.
In this menu you can also access add-on functions at a later
time.
TRAINING SOFTWARE
6
Download our free trainingLab-Software from the o-synce website.
This program allows you to transfer and analyse training data.
Using the integrated Workout editor you can quickly and easily
create training sessions on your PC.
TRAINING PLANS
The online portal Trainingsplan.com can automatically generate a
customised training plan for you without you requiring specialist
knowledge. You can load the data direct to your navi2coach
device.
USING THE TRAINING FUNCTIONS
8
The navi2coach utilises the FIT-File Format in order to access instructions during a workout.
You can create workout-FIT-Files using our training software or download one from the many online
training portals which use this file format. Transfer the workout file onto the device using trainingLab
or by copying the file into the device Import folder when the navi2coach is shown as an external hard
drive (see step 7).
In the menu Training > Training plan you can access and begin a workout
OVERVIEW MAIN MENU
Use the upper and lower buttons to scroll through the menus, confirm the selection with the middle button.
Quickstart
Training
Access the Sport mode and start a recording straight away.
Contains all training information and
functions.
Training today
Starts the planned training for the
current day.
Manual Training
Creates a workout step-by-step which
can then be carried out.
Training plan
Lists all planned workouts.
Quickstart
Training data
Training
Shows a summary of all workouts
completed.
Navigation
Total
Geocache
Shows a summary of all recordings
(distance, time,calories, etc.)
Scales
Setting
Scales
(weight management)
If ANT+ scales are connected you
can use this function to save your
measurements.
GEOCACHING
The navi2coach allows you to join up with the popular "Geocaching" treasure hunts. Simply enter the cache co-ordinates
and allow the device to pilot the route. You can also plot a ride and play it back on the device.
Status bar
Satellite signal strength
11:16 Time
Battery charge remaining
Compass rose
The arrow head always shows
towards north.
Map scale
Shows the current map sca-
le. You can change the zoom
level using the +/- buttons.
All manuals and user guides at all-guides.com
Fit the device to & release it from the mounting bracket
CHARGING THE BATTERY
3
RECORD TRAINING
5
In the main menu press the
2 Sec.
button, or select Quickstart. The Sport mode is
selected and the device automatically searches
for paired sensors.
The START/STOP button activates recordings,
whilst recording use the START/STOP button
to end or pause training.
START NAVIGATION
7
If you don't already have planned routes use one of
the popular planning portals e.g.
a route in either GPX or FIT format. Alternatively you
can use commercially available mapping software e.g.
MagicMaps.
Connect the
until it is recognised as an external drive with the name
navi2coach. Open the drive and copy the file created into
the Import folder.
TRAININGLAB.COM
You can access your data and start a ride from the menu
Navigation >
DETAILED MANUAL ONLINE
9
Find more detailed information about your navi2coach at
www.navi2coach.com
You can also download the full instruction manual as a PDF file
from our homepage.
DATA VIEW
You can view any data relevant to your training here. Using the menu
data fields. You can create multiple data pages and access them with the +/- buttons.
Navigation
Contains all navigation functions.
Routes
Select and follow planned routes which
have been loaded onto the device.
Track summary
Shows routes already ridden.
GPS
Retrieve the current GPS-coordinates.
Geocache
This function allows you to manually
enter Geocaches or to retrieve a
loaded Geocache.
Settings
*With an ANT+ power meter
This area contains all adjustment
options.
PAIRING — ANT+ Sensors combine
To enable the use of your ANT+ accessories with the navi2coach these accessories must be connected to the device. If the
pairing with the default settings in Step 4 did not work or have been skipped, you can catch up on this as follows.
Select all the ANT+ sensors. This occurs for example when you connect the heart rate monitor to the speed and
1
cadence sensors or move your power meter in motion. Make sure that all sensors are within a radius of 2m from
navi2coach.
2
Geocache Go to Settings > Sports Profiles> Profile 1-4 > Sensors > Pair
sensors and stores them in profile 1.
Shows the position of a
Geocache.
The navi2coach allows you to save up to
above procedure in which you select one of the sections 2-4. Make sure that you are at least 8m from the sensors that you
do not want to connect with the selected profile. You can repeat the process for all 4 sports profiles.
My position
If you want to add or change a sensor in a profile, proceed as follows:
Shows your current position in
relation to the route or a POI.
Go to Settings under the profile to edit from:
1
Track
2
Select the menu Sensors
Now the device searches the appropriate sensor and, when found, will save it.
Shows the route travelled.
Do you want to for example add/exchange the speed sensor in the sports section 1, proceed as follows:
Settings> Sports Profiles> Profile 1> Sensors> Speed> Pair.
so make sure that it is turned on.
Note: All 4 sports profiles are automatically using the same heart rate sensor.
START/STOP-
Quickstart
Training
Navigation
Geocache
Waage
Einstellungen
Gpsies.com to create
navi2coach to your computer and wait
navi2coach
Routes.
Settings > Display Pages you can freely configure the
Speed
Temperature
Riding time Sunrise
Distance Sunset
Stop watch Time
Altitude Altitude in meters (+/-)
Cadence Pedal power balance
Heart rate Gradient
Calories
Zones
Burned fat (g)
Above high zone setting
Below high zone setting
*Power (Watt)
*IF Intensity Factor AVG Average value
*NP Normalised power
MAX Maximum value
*TSS Training stress score
all. Now, the device searches for all available
4 sport profiles. If you want to have a second bike with other sensors, repeat the
Settings> Sports Profiles> Profile 1-4
and in the following menu select the existing sensor to be exchanged or edited.
The navi2coach will now look for a speed sensor,
IN THE BOX
KEY FUNCTIONS
POWER-button
Long key stroke
Turn device on-or-off
Menus – short key stroke
Leave current menu
Sport mode – short key stroke
Pause the recording
START & STOP-button
Main menus – short key stroke
Open the Sport mode and
start the Sensor search
Sport mode – short key stroke
Start or pause a recording
Sport mode – long key stroke
End and save the current recording
LAP-button
Sport mode – short key stroke
Save an interim time
Sport mode – long key stroke
Set a POI
Accessories (optional) Speed & Heart rate
Cadence heart2feel x
You can complement the
macro2sx com
navi2coach perfectly with our
macro2sx speed ANT+ scales
range of o-synce ANT+ acces-
macro2sx cad ANT+remote
sories and enjoy the complete
functionality of your training ANT+power measuring
computer.
NAVIGATION VIEW
In use the route is displayed as a track view with an additional arrow based navigation. The zoom function allows
you to see the route in detail. Additional functions such as backtrack navigation, route inversion and the saving
and access of POIs are possible too.
Status bar
Satellite signal strength
11:16 Time
Battery charge remaining
Waypoint
A designated waypoint on
the route.
Turning instruction
Turning instructions are shown with
corresponding distance information.
SUPPORT GUARANTEE
You can help us improve our customer service by sending We are only liable for damages in accordance to the
your comments or questions to our email address at statutory regulations in respect to our contractual partners.
www.o-synce.com. Please keep your purchase receipt or a Batteries are excluded from warranties. In case of a
copy of it in a safe place. warranty please contact the retailer where you purchased
your device. Batteries can be returned after use.
Phone: +49-6201 980 50-0
Fax: +49-6201 980 50-11 UPDATES
Email: support@o-synce.com
o-synce Europe GmbH
Thaddenstr. 14a Current soft- and firmware updates can be found on
69469 Weinheim www.o-synce.com
Germany
This product is compliant with the Directive 1999/5/EC. The relevant Declaration of Conformity is available at
http://www.o-synce.com/en/customer-support
DE EN
Upper button
Menus
Scroll up through the menus
Sport mode
Display training data: open further pages
(forwards)
Navigation view: zoom function (+)
Middle button
Menus
Confirm selection
Sport mode
Change between the display categories
(Data & Navigation)
Lower button
Menus
Scroll down through the menus
Sport mode
Display training data: open further pages
(backwards)
Navigation view: zoom function (-)
!ATTENTION PAIRING!
If you want to use ANT+ accessories
with the navi2coach you must pair/
connect them first. The pairing function
is described in Settings >> Pairing.
Compass rose
The arrow head always shows
towards north.
Route guide
Shows the current route and
the remaining route.
My position
Shows your current position
in relation to the route or
a POI.
Map scale
Shows the current map
scale. You can change the
zoom level using the +/-
buttons.
