Thank you for purchasing the ThermoTorch 3 Astro Red 3-in-1
Hand Warmer, Red Light and Power Bank! It has a built in
hand warmer feature that will provide up to 4 hours of scent
free heat, a 90 lumen, 3 mode LED flashlight and is capable
of charging your personal electronic devices, with its powerful
3350 mAh rechargeable lithium ion battery. It is a must have
for any serious outdoor enthusiast!
WARNING: Read all instructions and warnings thoroughly before
using the ThermoTorch 3 Astro Red. Improper use
of this product may result in product damage,
excess heat, toxic fumes, fire or explosion. Not
intended for children.
WHAT'S IN THE BOX:
1 - ThermoTorch 3 Astro Red
1 - USB Cable
THERMOTORCH 3 ASTRO RED
7
6 5
1. Flashlight with 90 lumen red LED
2. Power button with hand warmer LED indicator
3. Main heating surface/handle
4. End cap
5. USB "OUT" port: (standard 2.0 ) 5V - 2.1A
6. Battery indicator LEDs (4)
7. Mini USB "IN" port
1. CHARGING THE INTERNAL LITHIUM
ION BATTERY
Your ThermoTorch 3 Astro Red has an internal, 3350 mAh re-
chargeable lithium ion battery, which allows for up to 4 hours of
continuous use at a constant temperature of up to 113° Fahrenheit
(45° Celsius).
The ThermoTorch 3 Astro Red ships with a partial charge, but you
should charge it completely before using it for the first time.
STEPS
1. Unscrew the end cap (4) to expose the USB ports (the cap
will stay tethered to the main housing via nylon cord).
2. Plug the standard USB plug end of the included USB cable into
a USB port on a PC, laptop, car charger or USB 5V 2.1A Max
adapter plug.
3. Plug the mini USB end of the included USB cable into the "IN"
port (7) on your ThermoTorch 3 Astro Red.
4. Once plugged in, the red LEDs (6) will start blinking indicating
a charge is in progress.
5. Charging is complete when all 4 red LEDs (6) stop blinking.
2. USING THE FLASHLIGHT
• Press and release the power button (2) to turn on the flashlight.
• The flashlight has 3 modes: Low, Medium and High.
• Each press and release of the power button will toggle through
the modes and then power the flashlight off.
3. USING THE HAND WARMER FEATURE
1 • Press and hold the power button (2) until the button illuminates red.
• This indicates the hand warmer is in use and the main heating
surface (3) will begin to heat up. In minutes, it will reach its
2
maximum temperature.
• Press and hold the power button (2) to turn off the hand warmer.
3
4. CHARGING AN EXTERNAL DEVICE
• Simply plug your device's USB 2.0 plug into the standard USB
"OUT" port (5) on the ThermoTorch 3 Astro Red while the other
end of your charging cable is connected to your smartphone,
4
tablet, camera or MP3 player.
• The internal battery will automatically start charging your device.
NOTE: The USB OUT Port is rated at 5v-2.1A out, which is designed
to work best with tablets.
• The battery indicator LEDs (6) will display the battery power
while you charge (1 LED- 25%, 2 LEDs- 50%, 3 LEDs- 75%,
4 LEDs- 100%).
5. SPECIFICATIONS
BATTERY: Rechargeable lithium ion battery– 3350 mAh
INPUT: Mini USB Connector / 5V 1.8A Max
HAND WARMER CONTINUOUS USE TIME: Up to 4 hours
continuous use (based on fully charged battery)
HAND WARMER TEMPERATURE RANGE:
UP TO 113° F (45° C)
FLASHLIGHT FEATURE:
3 MODES
1. LOW: 22 Lumens / 15 hours
2. MED: 45 Lumens / 10 hours
3. HIGH: 90 Lumens / 3.5 hours
C-LINK FEATURE: Compatible with other Celestron Elements
power banks for extending heat time and recharging the
internal battery
OUTPUT: Standard 2.0 USB port: 5V- 2.1A
(Smart Charge Technology)
AUTO-CHARGE FEATURE:
Plug into the standard USB port and
ThermoTorch 3 Astro Red will automatically start charging your
electronic device.
LED STATUS INDICATORS:
(4) Red- Battery indicator LEDs
(1) Red- Hand warmer indicator (power button)
OPERATING TEMPERATURE RANGE:
32° to 113° Fahrenheit (0° to 45° Celsius)
S
TORAGE TEMPERATURE RANGE:
68° to 77° Fahrenheit (optimal)
WEIGHT: 10.6 oz. (300 grams)
DIMENSIONS: 6.14 in x 1.74 in x 1.74 in
(155.9 mm x 44 mm x 44 mm)
POWER DELIVERY CHART:
iPhone XS (2658 mAh): 1.3 charges
iPad 4th (11,560 mAh): 0.3 charges
GoPro Hero 7 (1220 mAh): 2.7 charges
WARNINGS:
Read all instructions and warnings prior to using this product.
Improper use of this product may result in product damage,
excess heat, toxic fumes, fire or explosion, for which damages
you ("Purchaser"), and not Smart Team or Celestron (collectively
"Manufacturer") are responsible.
• Do not store battery in high temperature environment, including
intense sunlight.
• Do not place battery in fire or other excessively hot
environments.
• Be cautious of excessive drops, bumps, abrasions or other
impacts to this battery. If there is any damage to the battery
such as dents, punctures, tears, deformities or corrosion, due
to any cause, discontinue use and contact manufacturer or
dispose of it in an appropriate manner at your local battery
recycling center.
