THI 60401 Gebrauchsanweisung

Battery Pack
BATTERY PACK
60401 BATTERY PACK
INSTRUCTIONS FOR USE - ENGLISH
IMPORTANT INFORMATION
The words WARNING, CAUTION, and NOTE have special meaning and should be
reviewed.
WARNING A WARNING highlights a safety-related issue. ALWAYS comply
with this information to prevent patient and/or healthcare staff
injury.
CAUTION A CAUTION highlights a product reliability issue. ALWAYS comply
with this information to prevent product damage.
NOTE A NOTE supplements and/or clarifi es procedural information.
COMPLIANCE STATEMENTS
This rechargeable Lithium Ion battery pack REF 60401 has been tested and has met
the requirements of the following applicable regulations:
• IEC 62133:2002
• FCC Title 47 CFR, Part 15, Class B/ IECS-003, IV edition
• ROHS Directive 2002/95/EC
• Batteries Directive 2006/66/EC and subsequent amendments
• EMC Directive 2004/108/EC
• UN Transportation Testing – UN DOT 38.3 (T1-T8) Lithium Batteries
INDICATIONS FOR USE
This battery pack is designed for use with the OXYGEN and ViVi
Systems are intended to be worn by surgical personnel to provide a barrier be-
tween the operating environment and the surgical personnel in order to help pro-
tect against contamination and/or exposure of infectious body fl uids and harmful
microorganisms.
FOR USE WITH
• Use this battery pack to power:
REF 80100 ViVi ® Helmet,
REF 80120 ViVi Helmet w/ Headlight,
®
REF 70100 OXYGEN Aerolyte Helmet XS-XL,
REF 70110 OXYGEN Aerolyte Helmet M-4XL,
REF 70120 OXYGEN Aerolyte LED Helmet XS-XL,
REF 70130 OXYGEN Aerolyte LED Helmet M-4XL.
• Charge this battery pack only with REF 60500 Battery Charger.
SYMBOL DEFINITIONS
These symbols are located on the device and/or labels and are defi ned as follows:
SYMBOL DEFINITION
Caution, consult accompanying documents
Waste Electrical and Electronic Equipment Directive (WEEE)
Recyclable Product (see section 'Disposal/Recycling')
LI-ion
Temperature Limitation
Direct Current (DC)
CE Mark
Serial Number
Catalog number
Manufacturer
© THI GmbH 2020/05
ENGLISH (EN) - DEUTSCH (DE) - ITALIANO (IT)
TECHNICAL SPECIFICATION
MODEL
Description
European Conformity
Cell chemistry
Voltage (nominal)
Capacity (rated)
Cycle life characteristics
Ingress Protection (IP)
Mode of operation
Charging time
Battery life
Mass
LIMITATIONS OF USE
System. These
®
WARNINGS:
• Upon delivery and before each use, inspect the battery pack to check for any
eventual damage. DO NOT drain the battery if it seems damaged. DO NOT use
a battery that emits odors, generates heat, or shows discoloration or leakage.
• DO NOT expose the battery pack to heat, fi re, or shock.
• DO NOT heat the battery over 80 °C (176 °F).
• Exposure to high temperatures can reduce battery capacity and performance.
• DO NOT expose the battery to sources of heat or sunlight.
• DO NOT use this equipment in the presence of mixtures containing anesthetic
substances, fl ammable air, oxygen or nitrous oxide.
• Unless otherwise indicated, DO NOT sterilize or immerse the battery pack in
water, solvents, lubricants or other cleansing chemicals, or even expose them to
those substances. Keep the battery clean and dry.
• DO NOT short-circuit, crush, open, tear, incinerate, or disassemble the bat-
tery pack. Never store a bulk of batteries in a box or drawer where they could
short-circuit or be short-circuited by metallic objects. Damage increases the
risk of chemical burns due to electrolyte spills, fi re or explosion. For replacement
instructions, contact your local distributor.
• In case of leakage of liquids from the battery, avoid skin contact. In case of con-
tact, wash the aff ected area with plenty of water and consult a doctor. In case of
ingestion of a cell or whole battery pack, consult your doctor immediately. Keep
the battery pack out of reach of children.
• DO NOT use batteries other than those specifi cally designed for the OXYGEN
and ViVi
tric shock, or injury.
• Use the battery pack only for the intended applications.
• When using medical equipment, such as this battery pack, comply with the elec-
tromagnetic compatibility (CEM) procedures provided by your hospital.
RECOMMENDATIONS FOR BATTERY HANDLING
• DO NOT remove the battery from its original packaging until it is used.
• Upon delivery, your battery is in a shipping mode and will not deliver power.
Before fi rst use, put the battery into the charger to wake it up.
• After long storage periods, a full charging/discharging cycle might be necessary
to regain full battery capacity.
• Dispose the battery pack as described in the Disposal / Recycling section of
this manual.
• Rechargeable batteries achieve their optimum performance at room tempera-
ture, at 20 °C ± 5 °C (68 °F ± 10 °F).
• Store the original product documentation for future reference.
CHARGING INSTRUCTIONS
• For detailed instructions, consult the operator manual of the ViVi
OXYGEN Helmet.
WARNINGS:
• ALWAYS use the REF 60500 Battery Charger to charge and store the battery pack.
INSTRUCTIONS FOR USE
REF 60401
Rechargeable Battery Pack
CE
Lithium Ion
14.8 V (DC)
2.950 mAh (43.6 Wh)
> 80 % of rated capacity after 400 duty cycles
IPX0
Continuous
4 hours
> 5 hours (with REF 80100 ViVi
> 3 1/2 hours (with REF 80120 ViVi
> 6 hours (with REF 70100, 70110
OXYGEN Aerolyte Helmets)
> 4 ½ hours (with REF 70120, 70130
OXYGEN Aerolyte LED Helmets)
250 g (8.8 oz)
System. The use of any other battery may cause fi re, explosion, elec-
®
EN - DE - IT 1
R ONLY
X
Helmet)
®
Helmet w/Headlight)
®
® Helmet and
REF 20602 | Rev-02
