Thank you for selecting the AD 808 antenna combiner system.
Please take some time to read carefully through this manual before setting up the equipment.
Supplied Accessories
1 x Manual
Application
The AD 808 is a 4-channel active antenna combiner operating in the frequency range from 600 to
900 MHz. Up to four wireless transmitters can be combined into one transmitting antenna for
professional multi-channel applications.
Technical Specifications
1. Bandwidth: 600 - 900 MHz
2. Channels: up to four transmitters
3. Indicator: will illuminate when input signal is > +6 dBm
4. Max. input power: +20 dBm (100 mW). Ideal intermodulation characteristic.
1. Controls and Indicators
Front view
Power On/Off switch. LED will illuminate when power is on.
LED for Input Signal. The LED will illuminate, when the input signal is > +6 dBm.
8
