DeAR cUStoMeR,
We congratulate you on acquiring this MAGnAt
car Stereo Product.
Please read these instructions carefully
so as to ensure optimum and disturbance-
free functioning of the appliance. Technical
modifications reserved.
POSITIONING AND SECURING THE SPEAKER
SYSTEM (FIG. 1)
Use the mounting positions provided in your
vehicle. if the speakers do not fit, they can be
placed in the rear window shelf.
Fig. 1
(1) Depth
(2) Driver diameter
Fig. 1A
(1) Use mounting ring to mark position of speaker
opening and fastening holes
(2) cut out opening and drill holes
Make sure that the subwoofer is secured in
such a way that it cannot slip or slide. Use the
screws provided for this purpose. Damage
resulting from sudden changes in speed (e.g.
hard braking) is not covered under the terms
of our guarantee.
CONNECTING TO THE RADIO / AMPLIFIER
(FIG. 2)
the speaker system should preferably be
connected to an external power amplifier. this
can provide the required electrical power and
create corresponding dynamic reserves. the
relevant instructions also contain the customized
connection diagram for the operation of a speaker
system.
Should you not have a power amplifier, the
speakers can also be connected directly to the
radio. the relevant operating instructions also
contain the connection diagram for this situation.
Please note that only limited dynamic reserves
will be available in this case. Excessively low
outputs combined with high distortions can
destroy your speakers.
TWEETER LEVEL SWITCH (REFERENCE
SELECTION 216, PRO SELECTION 216/213)
(FIG. 2C)
this switch can be used to raise or lower the
tweeter level by 3 dB. the best position can be
determined by listening and trying it out.
TWEETER PROTECTION
(REFERENCE
SELECTION 216/213)
there is a protective element integrated into the
crossover of your RefeRence Selection/
PRo Selection tweeter, which has high
impedance in cases of overload and reduces the
current flowing through the tweeter. if the tweeter is
deactivated, please turn down the volume and wait
for a moment. After cooling down, the tweeter will
re-activate and is ready for operation again.
INSTALLING THE TWEETER (REFERENCE
SELECTION 216, PRO SELECTION 216/213)
(FIG. 3)
INSTALLING THE GRILLE (FIG. 4)
4
POLYSWITCH
SELECTION 216, PRO
