Accessory - purchase separately
(PSE.VK)
1
A
!
LED's should not be touched
during installation and servicing.
3b
3b
CMS Mounting
Luminaire to Cable Management
System Fixing Kit (1247 - S0001)
Rubber washer
x4
M6 flat washer
No.12 x 5/8 screw self tapping
Recommended Torque: 4Nm
2
B
C
A
x2/x3
Handle reflector with care
4
A
C
L
N
D1 D2
DALI
3a
3a
Ceiling Mounting
Fixing Hole Centres
L024
L054/L094 = 1000mm x 77mm
L064/L114 = 1300 x 77mm
Secure luminaire to ceiling using
suitable fasteners supplied by others
For CMS mounting see 3b
For alternate mounting sea un-used holes with plugs provided.
5
IP65 Cable entry gland
to suit 19mm o/d hole.
Gland supplied by others.
B
= 400mm x 77mm
A
B
x2/x3
