1.9 Trouble-shooting / FAQ
1. Display does not light
-
PSU is not plugged in
-
Power supply connection is faulty
2. Does the GATE indicator light up when you play your MIDI keyboard?
No
:
- The MIDI channel does not correspond with the MIDI keyboard. Set the MIDI
channel described in Operations.
- MIDI connection is faulty / not correct
Yes
:
- The connection to the sound mixer is not correct
- VOLUME is zero
- Sound mixer is not set correctly
3. The GATE indicator does work but there is no sound or very distorted sound
-
You have probably connected a DC power adapter and not an AC (alternating current).
Make sure you use an AC adapter providing 8V AC with the capability to deliver 500mA.
1.10 Waves
0
Sawtooth
1
Square
2
Pulse 1
3
Pulse 2
4
2. Harmonic
5
3. Harmonic
6
4. Harmonic
7
Triangle
8
Sawtooth+Square
9
Sync Square
10
Sync Sawtooth
11
Synth Highpass
12-17
Synth
18-21
Organ
22-28
Synth
29+30
Synth Bell
31-55
Synth
56-61
Organ
62+63
Synth
64-68
Synth Highpass
69-74
Synth
75+76
Organ
77-82
Synth
83+84
Organ
85-98
Synth
99
No Wave
Syntrack
Synthesizer
