Menabo JUZA Montageanleitung Seite 8

T-system
9
x
x: 20 mm / 0,8"
B
W
Ømin 25mm/1" W: min 25mm/1"//max 60mm/2.3"
Ømax 60mm/2.3" H: min 25mm/1" //max 60mm/2.3"
A
B
H
H
W
-9-
A
NO
B
MIN 22"
MAX 75mm / 3"
MAX 29"
OK
MAX 1300mm / 51.2"
