MANUAL IN ENGLISH
4
Overview
1 Ring light
2 Locking screw (tilt angle)
3 Locking screw
4
Bracket for light stand
5 Accessories connection
6 Battery slots
7
On / Off switch
8 Power supply
9
Colour temperature control knob
10 Brightness control knob
Installation:
A Place the ring light with the bracket
(4) to a light stand with spigot and
tighten the locking screw (3).
B Loosen the locking screw for the tilt
function (2) and set the desired illumi-
nation angle.
Use with power supply unit: Please
C
plug the supplied power cable into
the power connection (8). Slide the
on/off switch (7) to the "
to turn on the LED light.
D Use with rechargeable batteries:
Place the batteries in the battery slots
and set the on/off switch to the "
symbol to turn on the LED light.
Note: Rechargeable batteries and
charger are optionally available from
Rollei. 2 pieces Li-Ion (spare) Sony
NP-F750/F970
E To mount the ball head or smart-
phone holder, screw the accessories
onto the 1/4 inch connector (5).
F After turning on the power, turn the
control knob (10) to the left or right
to increase or decrease the brightness.
To change the color temperature, turn the control knob (9) to the left or right to
increase or decrease the Kelvin value.
Note: The color temperature can be set between 3200K and 6500K in.
2
" symbol
"
ENGLISH
1
6
7
3
4
A B
C D
5
E F
5
9
10
8
10
9
