Nordic NE1V2 Installationsanleitung

Pre-check and Adjust Before Installation
If the heights of the two columns are inconsistent, the columns
need to be adjusted to the lowest position before product
assembly. The adjustment method is shown in the figure.
The two columns are in the same lowest height.
1
7
14
The down button
Connect to power after wiring the column(3) ,adapter(7) and handset(12)
to the control box(14). Then press the down button to adjust the column
to the lowest position.
2
Rotate
Insert the transmission rod(5) to the column(2), Turn the transmission rod
clockwise and adjust the column to the lowest height.
