Installing
FMU Plug-in Module
Inserting MUX Demux modules in a 1U 2-slot chassis
1. Align the module with the chassis shelf.
2. Gently push the module into the shelf cavity.
3. Press on the M3 captive screws rst and then tighten it on each side.
NOTE:
Put the top surface of FMU module close to the cover of chassis for easy
installation.
Mounting the equipment in a rack
1. Place the track mounting bracket on the desired position.
5
