Targetti LED.Y PROJECTOR Montageanleitungen Seite 2

Non incluso
Not included
Ø5mm
Blue
Blu
1E1385
Brown
Marrone
BOX IP68
Non incluso
Not included
Blu
Marrone Marrone
+ - + -
Brown
Brown Blue
CONNESSIONE IN SERIE
UTILIZZARE CAVO
H07RN-F 2x1,5mm² MAX
ØMin 6mm ØMax12mm
O EQUIVALENTE
USE CABLE
H07RN-F 2x1,5mm² MAX
ØMin 6mm ØMax12mm
OR EQUIVALENT
MAX 6 PROJECTORS
Blu Blu
Marrone
+ -
Blue
Blue
Brown
SERIES WIRING
2Y56CS00
TARGETTI
