5. Stand lnstalla�on
1. Open the package and take out the product with Styrofoam s�ll a�ached.
Gently place it on a table.
2. Take out the upper Styrofoam and the inner package bag, lower Styrofoam
place on a table, keep the lower foam underneath the monitor.
3. See picture, fasten the stand stem and base with a screw.
4. Press the bu�on to remove the stand plate. Fix the stand plate into the
stand stem with the screw PM5*11mm.
stand plate
5. Fix the whole assembled stand into the monitor,and check carefully to
make sure it is fasten.
Bu�on
Eng-4
Screw
PM5*11mm
Screw
PM5*11mm
