Logic3 Action Pad Handbuch

Thank you for purchasing the Logic3 Action Pad. As with all Logic3 products it has been built to the highest
manufacturing standards and tested throughout its development, to ensure you get the best possible
product. Please read through and familiarize yourself with this manual before you use the Action Pad.
Action Pad Controls
C
E
A & D
A.10 action/fire buttons (Buttons 11 & 12 are activated by depressing the L & R mini sticks)
B.Two analog triggers (7 & 8)
C. 8-way D-pad that can work as a hat switch or as a digital direction control
D. 2 analog mini sticks with auto-calibration and auto-centering
E. 2 high grade built-in motors for vibration feedback
F. Mode Button for Dual (Digital) / Hat Switch (Analog) mode selection
Hat Switch (Analog) Mode: (Press the mode button)
Left Mini Stick associates with X & Y axes, Right Mini Stick associates with Throttle & Rudder axes (Z & Rz)
D-pad works as 8-way POV (Point of View)
Dual (Digital) Mode: (Default setting)
X, Y directional axes can be controlled by both the D-pad or left mini stick
Right analogue stick will act as button 1,2,3,4
Action Pad (JP284) – EN User Manual
A
F
A & D
A
E
A
B
B
USB
