Poresta Systems Poresta BF Einbauanleitung Seite 6

Einbauanleitung
Mounting instruction
Montagehandleiding
Instructions de montage
Istruzioni di montaggio
Use:
- The shower system Poresta
size by the installer in due consideration of size, installation height
and geometry of the shower system.
- The kind of utilization of the shower space (splash protection, move-
ment area, etc.) is to be considered.
- For the installation of the shower system a level, clean, solid
surface free of vibrations and suited for fastening with Poresta
Flex must be available.
- The correct fitting of the discharge element is to be checked.
- The shower system is generally accessible for wheel chairs when
using tiles of a minimum size of 100 x 100 mm. If glass fabric is
worked into the tile adhesive bed, also tiles of a minimum size of
50 x 50 mm may be used for Poresta
- Suitable only for use indoor.
The relevant processing guidelines of all trades must be
observed.
For installation substructure elements (not included in supply,
1
see figs. 6a to 8b) or a cast screed base (see figs. 6b to
8b) are to be used. The height of the substructure element/
screed base is to be selected according to the difference in
height between the raw floor and the room flooring (see also
installation examples).
2
Edge insulation strips are to be provided locally.
3
Apply Poresta Profi Flex to both sides
®
The drain fitting must possibly be lined with suitable sound
4
absorbing material.
After the installation of the drain fitting, a leakage test must
5
be carried out.
The processing instructions of the sealing system are to be
6
observed.
BF may be circumferentially cut into
®
BF.
®
Example for installation with Poresta
Mounting height/finished floor level
Poresta BF
®
2 layers of Poresta
Poresta UBE substructure element (X)
®
Installation example with screed base (Y):
Profi
®
Mounting height/finished floor level
Poresta ® BF
1 layer of Poresta
Screed base (Y)
The shower system Poresta
materials of construction material class B2.
UBE substructure element (X):
®
Profi Flex
®
Profi Flex
®
BF meets the requirements relating to the construction
®
Poresta BF
®
120 mm
- 50 mm
-10 mm
= 60 mm
120 mm
- 50 mm
- 5 mm
= 65 mm
