Preparation For Use; Assembly - Metasys Meta Touch Gebrauchsanweisung

Preparation for use

EN |
Wall mounting
Quantity dispensed
Cleaning
Manufacturer
3. Preparation for use
> When using as a soap dispenser, install the dispenser as close as possible to the sink to prevent wet hands from
dripping onto the floor.
> Required space above the dispenser: 50-70 mm for the lever, and for dispenser removal and placement, as well as
an additional 100 mm for operation. The required room below the dispenser, necessary for bottle removal, is about
170 mm.
> Optimal mounting height for use: 130-135 cm, measured from the floor to the upper edge of the dispenser housing.
4.

Assembly

1
12
wall mounting with 3 screws and dowels
adjustable, 1.5 ml / stroke (depending on the viscosity of the product)
dispenser dishwasher safe and autoclavable up to 134 ° C, 2 bar
Ophardt Ireland, Tubbercurry Road, Ballymote, Co. Sligo, Ireland
First remove the bottle: Tilt the bottom of the inserted bottle slightly for-
wards and remove the bottle from the dispenser.
