Specification - digimess HV10001 Gebrauchsanweisung

2.2Specifications
Model No HV10001
Order No HUC46-01
No of outputs
Single
Output voltage
0-100V
Output current
0-1A
Line regulation
CV<0.02% + 3mV
CC<0.5% + 3mA
Load regulation
CV<0.01% + 5mV
CC<0.2% + 5mA
Ripple & noise
CV<10mVrms
CC<60mArms
Display
2 x 3.5 digit LED
Accuracy :
V - 1.0% + 2 dig
I - 2.0% + 2 dig
Input voltage 110/220V +/- 10% AC (external selector switch)
Dimensions
291 x 158 x 136mm
Weight 4kg
5

Specification

HV20001
HUC46-02
Single
0-200V
0-1A
CV<0.02% + 3mV
CC<0.5% + 3mA
CV<0.02% + 10mV
CC<0.5% + 5mA
CV<10mVrms
CC<60mArms
2 x 3.5 digit LED
Accuracy :
V - 1.0% + 2 dig
I - 2.0% + 2 dig
365 x 265 x 164mm
7kg
HV30001
HUC46-03
Single
0-300V
0-1A
CV<0.02% + 3mV
CC<0.5% + 3mA
CV<0.02% + 10mV
CC<0.5% + 5mA
CV<10mVrms
CC<60mArms
2 x 3.5 digit LED
Accuracy :
V - 1.0% + 2 dig
I - 2.0% + 2 dig
365 x 265 x 164mm
7kg
