Appropriate Use; Scope Of Delivery; Installation/Disassembly - SimonsVoss SREL3.COVER Kurzanleitung

SREL3.COVER

2 Appropriate use

The SREL3.COVER is a vandalism protection frame for the second-
generation SmartRelay 3 reader in grey or white and in a normal or
waterproof design (.WP).
This frame will also protect your device from external forceful impact.
The reader is available in a WP version (waterproof) for additional
weather protection.

3 Scope of delivery







4 Installation/disassembly

1. Remove the vandalism protection housing frame.
2. Position the base plate on a level surface, ensuring it is straight.
EN
1× vandalism protection frame, consisting of base plate and frame
2× safety screws with TXB-10 pin drive (pre-assembled)
1× TXB-10 screwdriver bit with hole
2× A2 button head screws (DIN 7996 5×50 mm, PZ2)
2× dowels (Fischer SX8)
2. Appropriate use
17 / 80
