Operating Instructions
Globe-Shaped Power Socket
Item No. 2267531 (5 sockets)
Item No. 2267532 (3 sockets, 2 USB-A)
Intended use
The product is a power socket that comes with a
surface mount.
Item No. 2267532 has 2x USB-A charging ports and
switchable power sockets.
It is intended for indoor use only. Do not use it out-
doors. Contact with moisture, e.g. in bathrooms,
must be avoided under all circumstances.
For safety and approval purposes, you must not re-
build and/or modify this product. If you use the prod-
uct for purposes other than those described above,
the product may be damaged. In addition, improper
use can result in short circuits, fires, electric shocks
or other hazards. Read the instructions carefully and
store them in a safe place. Make this product avail-
able to third parties only together with its operating
instructions.
This product complies with the statutory national and
European requirements. All company names and
product names are trademarks of their respective
owners. All rights reserved.
Delivery content
•
Power globe
•
Table mount
•
4x mounting screws
•
Operating instructions
Up-to-date operating instructions
Download the latest operating instructions at
www.conrad.com/downloads or scan the QR code
shown. Follow the instructions on the website.
Explanation of symbols
The symbol with the lightning in the
triangle is used if there is a risk to your
health, e.g. due to an electric shock.
The symbol with the exclamation mark in
the triangle is used to indicate important
information in these operating instructions.
Always read this information carefully.
The arrow symbol indicates special in-
formation and advice on operation.
The product must only be installed and
used in dry, indoor locations. It must not
become damp or wet, as this may cause
a fatal electric shock!
Safety instructions
Read the operating instructions
carefully and especially observe
the safety information. If you do not
follow the safety instructions and
information on proper handling in
this manual, we assume no liability
for any resulting personal injury or
damage to property. Such cases will
invalidate the warranty/guarantee.
a) Special safety
• Do not connect the product
in series!
• Do not operate the device
while covered.
• De-energised only when un-
plugged.
• Only use in dry rooms.
b) General information
• The device is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the appliance from extreme tempera-
tures, direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, im-
pacts or a fall even from a low height can damage
the product.
• Consult an expert when in doubt about the opera-
tion, safety or connection of the appliance.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised re-
pair centre.
• If you have questions which remain unanswered
by these operating instructions, contact our tech-
nical support service or other technical personnel.
c) Connected devices
• Also observe the safety and operating instruc-
tions of any other devices which are connected
to the product.
d) Electrical safety
• Never pull the mains plug from the socket by
pulling at the cable. Always pull it from the mains
socket using the intended grips.
• Unplug the mains plug from the mains socket if
you do not use the device for an extended period
of time.
• Disconnect the mains plug from the mains socket
in thunderstorms for reasons of safety.
• Make sure that the mains cable is not squeezed,
bent, damaged by sharp edges or put under me-
chanical stress. Avoid excessive thermal stress
on the mains cable from extreme heat or cold.
• Do not modify the mains cable. Otherwise the
mains cable may be damaged. A damaged mains
cable can cause a deadly electric shock.
• Do not touch the mains cable if it is damaged.
First, power down the respective mains socket
(e.g. residual current circuit breaker) and then
carefully pull the mains plug from the mains
socket. Never use the product if the mains cable
is damaged.
• A damaged mains cable may only be replaced by
the manufacturer, a workshop commissioned by
the manufacturer or a similarly qualified person,
so as to prevent any danger.
• Never plug in or unplug the mains plug when your
hands are wet.
• Connect the appliance to a wall socket that can
be accessed easily.
• Always lay the cables so that nobody can trip over
or become entangled in them. This poses a risk
of injury.
• The product is equipped with an enhanced pro-
tection against accidental contact. An integrated
mechanism will release the holes of the recep-
tacle only, if the two prongs of a power plug are
inserted into the two holes at once.
• Take special caution when children are around.
Children cannot recognize the danger arising
from the incorrect use of electrical devices. There
is a risk of a life-threatening electric shock!
Warning labels
Warning labels are included in the package. Stick a label in your language over or next to the language label
on the product.
Mounting
Important
•
The included screws
can be used to fix the mount to a surface, e.g. Underneath a wooden desk.
•
Check that the screws are suitable for the surface material.
•
Make sure there is nothing beneath the surface that could be damaged and/or cause harm if
punctured, e.g. electric wiring.
•
If mounting to a table, make sure the screws are not too long.
1. Attach the mount to the globe to check the positioning before drilling the holes.
2. Consider the direction of the power cable when mounted.
3. Use the holes on the mount as a template to mark the position before screwing it down.
Operation
•
Insert the power plug into a properly earthed mains socket e.g. wall socket.
You can organize excess cable by wrapping it around the globe (between the base and the
mount).
Care and cleaning
•
Disconnect any peripherals and the product from the mains before each cleaning.
•
Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as they can
cause damage to the housing and malfunctioning.
•
Clean the product with a dry, fibre-free cloth.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product in accordance with applicable regulatory
guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the environment.
Technical data
Rated voltage
Rated current
Rated power
USB ports
Power sockets
USB ports
USB port protection
Cable type
Product material
Enhanced protection against
accidental contact
Operating/Storage conditions
Dimensions (W x H x D)
Weight
USB port data for item no. 2267532:
Input voltage
Input AC frequency
Output voltage
Output current
Output power
Average active efficiency
Efficiency at low load (10%)
No load power consumption
Model identifier
Commercial registration number
Manufacturer
Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2020 by Conrad Electronic SE.
Item no. 2267531
Item no. 2267532
250 V/AC
max. 16 A
max. 3680 W
-
5 V/DC 2.1 A, max. 10.5 W
5 (continuous)
3 (switchable)
-
2 (switchable)
over-voltage, short-circuit,
-
overloading
H05VV-F 3G1, 5 mm²
PC
Yes
-10 to +50 ºC, 10 – 90 % RH (non-condensing)
79 x 79 x 90 mm
380 g
230 V
50 Hz
5.0 V/DC
2.1 A
10.5 W
81.6 %
78.9 %
0.42 W
GPBKU03/D-M
HRB 3896
*2267531_2267532_v3_1220_02_dh_m_en
