LC RACING EMB CHASSIS CLEAR BODY Bedienungsanleitung Seite 7

D-3
HM6076-B HM6038
3x3mm (1)
HM6042 HM6072
7x11x3mm (1)
step 1
BE6013
BE6013
BE6000
complete
D-4
HM6065
2.6x8mm (10)
HM6021
4.3x6mm (2)
HM6044
(2)
HM6076-B
3x3mm (2)
HM6041
4x8x3mm (1)
M4 (1)
2.0x4mm (1) HM6039
1.5x6mm (3)
step 2 step 3
HM6035
HM6110
4x7x2.5mm
step 7 Thread Lock
HM6076-B
3x3mm
HM6038
7mm
HM6033
BE6070
BE6069
7
1/14 SCALE Radio Control 4WD
Short Course Truck
HM6110
4x7x2.5mm (1)
HM6033
(1)
HM6039
HM6040
1.5x6mm
HM6001
Thread Lock
HM6072
2.0x4mm
HM6036
step 6
HM6004
HM6042
7x11x3mm
HM6076
HM6065
2.6x8mm
BE6019
HM6035
(1)
HM6004 HM6001
(1) (1)
step 4
HM6041
4x8x3mm
HM6039
1.5x6mm
step 5
HM6037
HM6065
2.6x8mm
HM6065
2.6x8mm
HM6044
HM6021
4.3mm
Differential Grease
