Installation on a Console (only NC4 - 125)

Fig. 12: Console for NC4 - 125
1 Clamping claw
Installation on a console, 100 mm high with external clamping claws (1).
NC4
Installation of NC4 on the Machine Table | 7
2 Grid plate
