COMQ
PC Camera for Teleconferencing & Video Surveillance
Introduction
Thank you for buying this high quality video webcam.
Following information will help you to use your cam-
era to its full capabilities. For viewing pictures or video,
camera must be connected to your personal computer.
This camera supports Microsoft Video Class and
Plug&Play directly without driver. For using special
features like "face tracking" or "snapshot" please
follow software installation steps.
System requirements
Pentium IV 1GHz or higher CPU
500MB free hard disk space
CD-ROM drive
512MB RAM
VGA card with DirectX 9.0 support
Windows 2000/XP SP2/Vista/7
Internet connection
Free USB 2.0 port
Package content
WebCam
Software CD-ROM
User manual
Hardware installation
Please plug camera into free USB 2.0 port
Software installation
Note: Please make sure the WebCam is plugged in
the USB port before proceeding.
1. Insert software disc into CD-ROM drive. If installa-
tion will not start automatically, open Setup.exe
from CD-ROM root folder.
2. When installation is completed, webcam icon will
appear in system tray.
Downloaded from www.Manualslib.com manuals search engine
Instructions Manual
3. Select AMCAP application from Start menu as
shown below.
Using AMCAP software
Video Preview
Click AMCAP to run application, if you cannot see the
picture click "Options" and choose "Preview" to enable
video preview.
Snapshot function
To capture a still image, right click on the webcam icon
form system tray and then select "Snapshot" and your
desired image size. A screen with a preview of the tak-
en photo will appear. To save the photo choose "File"
and then "Save as" and specify fi lename.
Changing
video
resolution
Select "Options"
and then "Video
Capture Pin" to
open following
window.
MT4028
EN
