Operating Instructions
USB2.0 Video-Grabber "BR116"
Item No. 2228152
Intended use
The product The product is intended to be connected to a USB port of a computer for digitising
an analogue AV signal (FBAS/SVideo signal and stereo-audio signal).
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bath-
rooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged. In
addition, improper use can result in short circuits, fires, electric shocks or other hazards. Read
the instructions carefully and store them in a safe place. Make this product available to third
parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• Video grabber with connection cable
• CD ROM
• Operating instructions
Up-to-date operating instructions
Download the latest operating instructions at www.conrad.com/downloads or
scan the QR code shown. Follow the instructions on the website.
Explanation of symbols
The symbol with the lightning in the triangle is used if there is a risk to your health,
e.g. due to an electric shock.
The symbol with the exclamation mark in the triangle is used to indicate important
information in these operating instructions. Always read this information carefully.
The arrow symbol indicates special information and advice on operation.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on
proper handling in this manual, we assume no liability for any resulting per-
sonal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
a) General information
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become dan-
gerous playing material for children.
• Protect the appliance from extreme temperatures, direct sunlight, strong jolts,
high humidity, moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Consult an expert when in doubt about the operation, safety or connection of
the appliance.
• Maintenance, modifications and repairs must only be completed by a technician
or an authorised repair centre.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
b) Connected devices
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
Connection and software installation
• Launch the operating system (Windows XP or higher) and wait until it is fully loaded.
• Plug the Video Grabber into a free USB 2.0 port on the computer (alternatively to a USB 3.0
port). Once connected to the computer, Windows will detect new hardware and will install
the required driver for the Video Grabber automatically.
• Insert the enclosed CD into the appropriate drive of your computer. If the installer does not
start automatically, run it manually. At the time of writing these operating instructions, you
had to run the program "Autorun.exe" from the main directory on the CD. On the screen
that appears click "Install VHS To DVD" to install the video digitizing software and follow the
instructions provided by the software.
• Start the software.
When you start the software for the first time, you have to enter the registration code,
which you will find on the back of the CD cover.
• Connect an AV source to the 3 RCA sockets (the yellow is for the video signal, the other two
for the audio signal). Alternatively, you could use the SVideo connector for the video signal
and the red/white RCA connector for the audio signal.
Tips and information
• Only use a USB 2.0 port otherwise there could be gaps and shakes in the video record.
Alternatively, you could also use an USB 3.0 port.
• On the CD you will find the English language manufacturer's directions for the software. To
view this you need a program that can open a PDF file (for example Acrobat Reader, which
can be downloaded for free at www.adobe.com).
Disposal
Electronic devices are recyclable waste and must not be disposed of in the house-
hold waste. At the end of its service life, dispose of the product in accordance with
applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the envi-
ronment.
Technical data
a) General
Supported formats ........................ NTSC, PAL
Video inputs .................................. 1x RCA composite
1x S-video
Audio input .................................... 3.5 mm RCA (stereo)
USB .............................................. bus power
Video resolution ............................ NTSC: 720 x 480 @ 30 fps
PAL: 720 x 576 @ 25 fps
Operating conditions ..................... -10 to +45 ºC, 20 – 75% RH (non-condensing)
Storage conditions ........................ -20 to +75 ºC, 20 – 75 % RH (non-condensing)
Dimensions ................................... 88 x 28 x 18 mm (L x W x H)
b) System requirements
USB .............................................. 2.0
Supported OS ............................... Windows
CPU .............................................. Pentium III 800 above
HD ................................................ 600 MB free space for program installation
4 GB free space for video capture and editing
RAM .............................................. min. 256 MB
Display .......................................... 1024 x 768 or higher
Audio ............................................ Windows
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represent the technical status at the time of printing.
Copyright 2020 by Conrad Electronic SE.
XP or above (32/64 bit)
®
compatible sound card
®
*2228152_v1_0420_02_dh_m_en
