子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm Warning and Notice Atenção!! Limite de altura para o dissipador do CPU: O limite de altura para o dissipador do CPU é 155 mm (6,1 polegadas). Limite de comprimento para VGA (placa gráfica): O limite de comprimento para VGA (placa gráfica) é...
子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm Side Panels Disassembly PSU Installation English / 繁體中文 / Place the power supply in proper location and 將電源供應器放在正確的位置,並用螺絲固定 secure it with screws. 鎖上。 English / 繁體中文 Remove the screws on the back of the chassis, 移除機殼後方螺絲,將側窗打開...
子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm Motherboard Installation 5.25" Device Installation English / 1. Pull out the front panel. 2. Remove the 5.25” drive bay cover. 3. Slide the 5.25” device into the drive bay to lock the device.
子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm HDD Cage Installation English / 繁體中文 / 1.Press a latch to pull the tray out. 1. 輕壓硬碟托盤左側開啟硬碟托盤,並向外拉出 2. Remove the locking clips then position the HDD 硬碟托盤。...
子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm PCI Card Installation Air Cooling Installation 12cm x 3 14cm x 3 Rear Front 12cm x 1 Bottom English / 繁體中文 / 將 PCI 卡插入 PCI 插槽,然後用螺絲固定。 Insert the PCI card into the PCI slot, and 14cm x 2 12cm x 2...
子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm Leads Installation Maximum Radiator Installation Notice English Leads Installation Guide Case LED Connection / On the front of the case, you can find some LEDs and switch leads. Please consult your user manual of your motherboard manufacturer, then connect these leads to the panel header on the motherboard.
Seite 11
子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm Français Italiano Guide d'installation des fils Guida di installazione dei contatti Connexion des voyants du boîtier / Sur la face avant du boîtier, vous trouverez plusieurs voyants et les fils des Connessione del LED del case / Nella parte anteriore del case, sono presenti alcuni contatti per interruttori e LED.
Seite 12
子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm 繁體中文 日 本 語 線材安裝說明 リード線の取り付けガイド 機殼LED連接方式 / 在機殼前方的面板後面,可以找到一些LED與開關線材(POWER Switch….),請參考主機板使用說明書, ケース LED の接続 / ケース前面には、LEDとスイッチリード線があります。 マザーボードメーカーのユーザーマニュアル 並將機殼上的線材正確地連接到主機板上,這些線材通常都會印有標籤在上面,如果沒有的話,請找出機殼前方面板上線材原 を参照し、これらのリード線をマザーボードのパネルヘッダに接続してください。 本的位置以知道正確的來源。 USB 3.0 の接続 / USB 3.0 連接 / 1.
Quality From Within คู ่ ม ื อ การติ ด ตั ้ ง สายไฟ Every power supply units from Thermaltake should pass a very strict quality control before sent to การเชื ่ อ มต่ อ ไฟ LED ของเคส / ที ่ ด ้ า นหน้ า ของเคส คุ ณ จะเห็ น ไฟ LED และสายไฟของสวิ ต ซ์...
Seite 14
子件料 號 版 本 發稿 日期 1 4/ 08/1 4 藍色線條為尺寸標示,請勿印刷上去! 刀模 125 mm Note: PRODUCT GM MARKETING CHECK 殊處理效果 Mike.Lin 無 Downloaded from www.Manualslib.com manuals search engine...
