Tele System TS 8500 PND Schnellstartanleitung Seite 11

Fig. G)
Clasp your navigator TS8500 PND
with the suitable holds of the cover
Fig. L)
Remove totally
support
WARNING!
The device had been deeply tested and again used in a normal drive. Anyway we advice to close or limit the
cold/hot air from the chosen air vent. We advice to perform the unmounting only when it is necessary.
Device description
1. LED
2. LCD Panel (Touch Screen)
3. Stand by key
4. SD card slot
5. Earphone output
6. Power input DC 5V
7. Switch ON/OFF
Downloaded from www.Manualslib.com
Fig. H)
After have removed your TS8500
PND, push a hook inwards of the
base
Fig. M)
the base of the
manuals search engine
Remove both the hooks from the air
vent of your vehicle
8. Vol + / -
9. External GPS module connector
10. RESET
11. Speaker
12. Touch screen pen
13. USB Slot
Quick Start Guide - ENGLISH
Fig. I)
Remove the hook from the base of the
support and repeat the operation as fig.
H) for the other hook
11
