NOTE
NOTE
Keep these instructions in a safe place and pass them on to
possible future owners.
1. Safety notes
ATTENTION!
This appliance can be used by children aged
from 8 ears and above and persons with
reduced
capabilities
knowledge if they have been given super-
vision or instruction concerning the use of the
appliance in a safe way and understand the
hazards involved. Children shall not play with
the appliance. Cleaning and user main-
tenance shall not be made by children without
supervision!
ATTENTION!
Children of less than 3 years should be kept
away unless continuosly supervised. Children
aged from 3 years and less than 8 years shall
only switch on/off the appliance provided that
it has been placed or installed in its intended
normal operating position and they have been
given supervision or instruction concerning
the use of the appliance in a safe way and
understand the hazards involved!
ATTENTION!
Children aged from 3 years and less than 8
years shall not plug in, regulate and clean the
appliance or perform user maintenance!
ATTENTION!
Some parts of this product can become very
hot and cause burns! Particular attention has
to be given where children and vulnerable
people are present!
ATTENTION!
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order to
avoid a hazard!
ATTENTION!
The heater must not be located beneath a
socket outlet!
www.dimplex.de
Downloaded from
www.Manualslib.com
physical,
sensory
or
or
lack
of
experience
manuals search engine
HL 185T, HL 185/2, HL 185/3, HL 185SW, Hl 185TSW
ATTENTION!
Do not cover the heating device with
any objects; fire hazard!
The device is only suitable for room heating within closed rooms.
Repairs and corrective measures must only be carried out
by a qualified technician.
Disconnect the power supply in the event of a fault (pull out
the device plug or switch off the fuse).
mental
Observe the minimum clearances.
or
ATTENTION!
The outer surfaces of the device, and in particular the air
outlet grid, become hot during operation.
Caution! Potential dangers can arise when the device
switches on automatically, e.g. devices which have been
covered or blocked by objects since they were last used can
cause fires.
Do not operate the heating device in rooms where highly
flammable substances are used (e.g. solvents, etc.).
Power cord must not be laid over the device.
2. Technical data
Type
HL 185 T
HL 185/2
HL 185/3
HL 185
SW
HL 185
TSW
Degree of protection:
Safety class:
Dimensions:
Weight:
3. Installation
The heating device may only be installed and operated on a ver-
tical wall, as shown.
Installation below a wall socket is not permitted.
The device plug and outlet must be accessible after installation.
Install the device in such a manner that the controls cannot be
touched by a person in the bathtub or under the shower.
In addition, a minimum clearance of 200 mm is to be maintained
in front of the unit (air inlet area).
The device must be mounted to the wall with 3 screws. The en-
closed plastic bag contains screws and dowels.
Observe the minimum clearances! Dimensions in mm.
hl185-en_ba · 04/14/E
Nominal
Voltage
Thermo-
output,
stat
frequency
2000 W,
230 V~
yes
50 Hz
1/N/PE
2000 W,
400 V~
none
50 Hz
2/PE
700 W,
230 V~
yes
50 Hz
1/N/PE
2000 W,
230 V~
none
50 Hz
1/N/PE
2000 W,
230 V~
yes
50 Hz
1/N/PE
IP21 (drip proof)
I (with protective conductor)
(W x H x D) 230 x 230 x 160 mm
4.6 kg
Plug
yes
none
yes
none
none
EN-6
