DAnfuss RX1 Installationsanweisungen Seite 6

RX2
Note: for mains voltage applications link terminals L and 2.
ELECTRONICS
A
ATTENTION: If replacing a previous version of the RX2 receiver please
use the new backplate supplied and wire as illustrated above.
RX2C
A B C 1 2 3 4 5 6
6
B C
N
L
ELECTRONICS
N
L COM
ZONE 1
1 2 3 4
COM ZONE
1 ON
COM ZONE 1 ZONE 1
ZONE 2
ON ON
5 6
ZONE ZONE
1 OFF 2 ON
ZONE 1 ZONE 2 ZONE 2
OFF
OFF ON
