General Info; Installation And Configuration; Troubleshooting - Perenio UV Mini Indigo Schnellstartanleitung

GENERAL INFO

Article
Specification
Recommended
1
Exposure Time
Casing 2
Scope of Supply
Warranty

INSTALLATION AND CONFIGURATION

1. Unpack the UV Lamp and connect it to the source of power using USB-MicroUSB Cable.
NOTE. Any suitable USB Charger (Output: 5V/0.5A) may be used to connect the device to the mains
socket.
2. Wait for the battery to be recharged (It will take no more than 4 hours, and when fully charged,
the LED Indicator of the Power Button will stop flashing red).
3. Disconnect the UV Lamp from the source of power and install it on a flat horizontal surface in the
desired area to be UV-disinfected.
4. Press the Power Button to start the UV exposure process.
NOTE that the UV exposure will start 15 seconds after pressing the Power Button, which allows the
User safely leave the room, or switch off the device during this period. The LED Indicator will be
blinking blue during the 15-second delay period.
5. The UV Lamp will be automatically switched off 30 minutes after the UV exposure process is started.
Switch it on again, if required.
SAFETY OPERATION RULES
The device shall be used as described in this QSG and a complete manual only. Any other use not
specified therein may cause fire and other hazards, as well as injury to persons. The most effective
way to use the device is in rooms with no air circulation at an ambient temperature of +24°C to
+26°C. It is forbidden to operate the device, if any part of the device is damaged or cracked. The
device shall not be installed outdoors, or near water including humidifiers. The device shall be kept
away from direct sunlight, moisture and vibration. It is not allowed to drop or throw the device, as
well as attempt to repair it on one's own. It is not allowed to use the device with a damaged USB-
MicroUSB cable, or put this cable near radiators, stoves or heaters. It is not allowed to use detergents
to clean any part of the device. If the UV tube is broken, all particles shall be swept into a plastic bag,
sealed and disposed of properly, as well as the room must be well-ventilated, because the device
contains mercury. Do not use a vacuum cleaner to pick up the waste and glass particles. Contact your
local waste collection agency for proper disposal procedures. Keep children away from the device,
because it may emit a light attractive to them. Serious injury and electrocution might be possible.
This device is intended to be operated by adults only.
WARNINGS AND PRECAUTIONS
UVC LIGHT IS HARMFUL TO EYES! DON'T LOOK AT THE UV TUBE DURING OPERATION!
The Portable UV Lamp is not a medical device. People, pets and plants must not present in the room
under UVC exposure. Read and understand all instructions and precautions in this QSG and a complete
manual. Failure to follow manufacturer instructions may result in fire, electric shock and other hazards,
as well as lead to serious injury to persons. Warnings, precautions and instructions herein cannot
cover all possible hazardous situations that may occur. User must show common sense when using
the device. It is forbidden to look into operating UV tube, because any UVC light exposure
causes significant eye damage, as well as may cause skin damage. So, whenever the device
is powered on, wear UV eye and skin protection. Ingestion or contact with mercury or its vapor
is hazardous to health. So, if the device is broken, avoid contact with mercury. It is forbidden to touch
the UV tube with wet hands. The device is not intended to be used for removal of active mold growth.
The UVC light exposure to existing mold growth can cause respiratory irritation and allergic symptoms.
The UVC light exposure may also cause fabric and painting discoloration. The UVC light of the device
does not provide a tanning effect, while its exposure to uncovered skin areas for more than 2-3
minutes will causes burns. Do not use incompatible USB Charger to recharge the device.

TROUBLESHOOTING

1. The UV Lamp does not power on: Low battery level. Recharge the battery.
2. The UV tube does not work: The UV tube is damaged, or the end of life of the UV tube occurred.
Replace the UV tube.
1 Please ventilate the room for at least 30 minutes after each UV lamp exposure. During the UV Lamp exposure, all
doors and windows in the room must be closed.
2
This device is for indoor installation only.
3 Manufactured by Perenio IoT spol s r.o. (Na Dlouhem 79, Ricany - Jazlovice 251 01, Czech Republic). Made in
China. See operating conditions and date of manufacture on the individual packaging. All information contained
herein is subject to amendments without prior notification of the User. For current information and details on the
device description and specification, connection process, certificates, warranty and quality issues, as well as the
Perenio Smart/Perenio Lite app functionality, see relevant Installation and Operation Manuals available for
downloading at perenio.com/documents. All trademarks and names herein are the property of their respective
owners.
4
PEMUV01 (White), PEMUV02 (Black)
5VDC (Input), 3.7V max, 500mA, 50/60Hz, 2.5W (Power), UVC light,
187nm and 253.7nm (Wavelength), 2,100μw/cm
(Coverage area),
(Capacity: 2,000mAh, charging time: 4 hours, discharge time: 2 hours).
Operating conditions: 0°C to +40°C, up to 50% RH (non-condensing).
Dimensions (LxWxH): 50 mm x 60 mm x 182 mm
30 minutes (for area of up to 2.5m
90 minutes (for area of up to 7.5m
IP20 Protection Class, bulb type T5, ABS plastic (Lamp casing), quartz glass
(UV tube)
UV Mini Indigo Portable UV Lamp, USB-MicroUSB Cable (0.6 m), Quick Start
Guide, Warranty Card
2 years (UV tube lifespan: 15,000 hours)
3
360° (Coverage angle),
2 ), 60 minutes (for area of up to 5m
2
)
Doc Date: 12/11/2020
©Perenio IoT spol s r.o.
2
(Intensity), up to 9m
non-removable battery
Version: 2.0.0
All Rights Reserved
2
2 ),
