Operating instructions
3 port, aluminum USB 3.0 hub
with USB-C™ plug
Item No. 1511622
Intended use
The product is designed for connection to the devices with USB-C™ connection. The product is
equipped with 3 standard USB-A 3.1 ports for data transfer. Besides, the USB-C™ connection
of the product can be used for charging a suitable device (e.g. a mobile phone).
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in
bathrooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged.
In addition, improper use may cause such hazards as short circuiting or data loss. Read the
instructions carefully and keep them. Make this product available to third parties only together
with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• USB 3.0 hub • Operating instructions
Latest operating instructions
Download the latest operating instructions via the link www.conrad.com/downloads or scan the
QR code shown. Follow the instructions on the website.
Explanation of symbols
An exclamation mark in a triangle indicates important instructions in this operating
manual that absolutely have to be observed.
The arrow symbol indicates specific tips and advice on operation.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on
proper handling in this manual, we assume no liability for any resulting personal
injury or damage to property. Such cases will invalidate the warranty/guarantee.
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become
dangerous playing material for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high
humidity, moisture, flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Make sure that the connection values of your mobile device match the respective
values of the product (see Technical data). Do not use the product for mobile
devices that require a charging voltage exceeding 20 V and a charging current
exceeding 2 A (2000 mA).
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
• Never use the product immediately after it has been brought from a cold room
into a warm one. The condensation generated could destroy the product. Allow
the device to reach room temperature before connecting and using it. This may
take several hours.
• Do not short-circuit the USB connectors.
• Make sure that the USB cables are not squeezed, bent or damaged by sharp
edges.
• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
Operating controls
1
2
3
Operation
Connect the USB-C™ plug of the product with the USB port of a computer.
Data transfer from/to USB devices only occurs via the three USB 3.0 A ports (3).
If the product is not used any more, disconnect it via your operating system. Then
remove the USB-C™ plug from the USB port.
• Charge a mobile device directly at the USB-C™ connection. Connect the USB-C™ cable of
your mobile device with the USB-C™ port (2). The charging cycle starts automatically.
• Monitor the charging cycle. If you wish to interrupt or end the charging cycle, disconnect the
USB cable from the mobile device or from the product.
• Disconnect the USB cable from the product and mobile device after the end of the charging
process.
Care and cleaning
• Before each cleaning, disconnect the product from all connected USB cables, mobile
devices, laptop etc.
• Never submerge the product in water.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Clean the product with a dry, fiber-free cloth.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product according to
the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
Technical data
Input voltage / current ........................................... 5 – 20 V, max. 2 A
Output voltage/current USB-C™ .......................... 5 – 20 V/max. 2 A
USB standard ....................................................... USB 3.1 gen. 1
Cable length ......................................................... 0.2 m
System requirements ............................................ OTG function, Android 4.X and higher/
Operating conditions ............................................. -10 to +60 ºC, 20 – 80 % RH
Storage conditions ................................................ -20 to +80 ºC, 10 – 90 % RH
Dimensions (L x W x H) ........................................ 75 x 37 x 11 mm
Weight .................................................................. 50 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2017 by Conrad Electronic SE.
