- Seite 1 COMPONENT SPEAKERS P152-S P16-S P165-S P1675-S P1T-S Serial Number: Date of Purchase: Installation & Operation Downloaded from www.Manualslib.com manuals search engine...
- Seite 2 fire and/or possible injury. ©2012 Rockford Corporation. All Rights Reversed. ROCKFORD FOSGATE, PUNCH and associated logos where applicable are registered trademarks of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice. For use in vehicles only.
- Seite 3 See pages 4-5 for additional dimensions CEA 2031 Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards. This means your speaker has the capacity to handle power under continuous demand, not instantaneous power handling that over time can damage voice coils.
- Seite 4 illus.-1.1 Downloaded from www.Manualslib.com manuals search engine...
- Seite 5 illus.-1.2 Downloaded from www.Manualslib.com manuals search engine...
-
Seite 6: Installation Considerations
Contents (1) Pair Punch Series Full Range Component Speakers (1) Pair of grilles/trim rings Mounting Hardware Installation Considerations Before beginning any installation, follow these simple rules: 1. Be sure to carefully read and understand the instructions before attempting to install these speakers. 2. - Seite 7 Wiring Standard - Integrated Concealed Crossover (ICC™) NOTE: For the P152-S and P1652-S, the crossover is integrated into the basket of the mid-bass driver. This component grade crossover allows for easy connection of the full component system without the need for an external crossover.
- Seite 8 Adapter Plate Template - 6.75” Hole Mounting Remove Shaded Areas to Mount 5.25" (P152-S) Adapter Plate Template - 6”x9” Hole Mounting Mounting for 5.25” (P152-S) *Remove Light Shaded Areas for 5”x7” Hole Mounting *Remove for Optional Tweeter illus.-4.1 Downloaded from www.Manualslib.com manuals search engine...
-
Seite 9: Mounting Template
Mounting Template P1675-S Mounting Holes 6.18" (157.00mm) P1675-S Hole Cutout 5.68" (144.2mm) Verify Scale Before Using 1.00" (25.40mm) Template 1.00" (25.40mm) illus.-5.1 Visit www.rockfordfosgate.com for additional mounting templates. Downloaded from www.Manualslib.com manuals search engine... - Seite 10 Considérations Concernant L’installation Consideraciones para la instalación Avant de commencer l’installation, suivez les règles ci-dessous: Antes de comenzar cualquier instalación, siga estas simples normas: Asegúrese de leer cuidadosamente y de entender las instrucciones antes de tratar de instalar estos Veillez à bien lire et comprendre les instructions avant d’essayer d’installer les haut-parleurs. altavoces.
- Seite 11 Einbauüberlegungen Considerazioni sull’installazione Befolgen Sie vor dem Einbau diese einfachen Regeln: Prima di iniziare qualsiasi operazione d’installazione, vi consigliamo di seguire queste semplici regole: Lesen Sie die Anleitung sorgfältig, bevor Sie versuchen diese Lautsprecher einzubauen. Assicuratevi di aver letto tutte le istruzioni con cura e di averle capite prima di effettuare qualsiasi tentativo d’installazione neiconfronti dell’unità.
- Seite 12 What is Covered This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate Dealers in the United States of America or its possessions. Product purchased by consumers from an Authorized Rockford Fosgate Dealer in another country are covered only by that country’s Distribu- tor and not by Rockford Corporation.
- Seite 13 Installation assistance availible at: www.rockfordfosgate.com/rftech R O C K F O R D F O S G A T E . C O M Downloaded from www.Manualslib.com manuals search engine...
