OPERATION ADVICE
•
Rotate the drive nut to drive the jaws apart to match the length of the spring and to com-
press as many windings as possible. See below.
•
Make sure the spring is clean where the jaws are mounted on the windings.
•
Preload compressor by turning the hand wheel until the jaws has a firm grip on the spring.
See figure J.
•
Compress the spring by rotating the drive nut using a socket wrench. It is also possible to us
an air wrench. (Limit torque to 120 Nm, in order not to overload the safety pin).
•
Do not continue to drive when the upper or lower travel ends of spring compressor are
reached.
•
When the spring has been safely compressed, remove the top bearing of the strut.
•
Before removing the bearing recheck that the spring is still firmly seated in the jaws. See
figure K.
Figure I
Figure J
