USING THE PRAXIS
8
7
1. DSP MODES
Press the DSP MODE button to scroll through the
Tone/DSP Modes.
1. NORMAL
2. GUITAR
3. KEYBOARD
4. DRUM
2. INPUTS
Two individual combination XLR / Jack inputs to
receive connection from instruments, playback
devices or mixing desks. Each Input has
dedicated level control.
3. MASTER VOLUME
Controls the overall output level.
4. MIX OUT
Both Inputs 1 and 2 are sent to the line level Mix
Out output channel.
5. LED SWITCH
Turns the blue front LED On/Off.
6. POWER SWITCH
Turns the Monitor On or Off.
7. VOLTAGE SELECT SWITCH
Although every effort has been made to select
the correct voltage for the region of use, please
check before powering up for the first time.
PRAXIS10
MUSICIAN MONITOR
6
2
4
8. IEC Socket with Fuse holder
Power input. Please use the power cable
provided in the box. Always replace fuse with the
correct type and rating for your supply voltage.
USE WITH SPEAKER STAND
The SubZero Praxis can be used with a standard
35mm PA Speaker Stand, and features two pole
mounting sockets which enable the monitor to be
angled perfectly for the performer.
The front socket is set to 0 degress. The rear socket
is set to 7 degreess.
6
1
3
5
0°
7°
