Fantec AIR-200 Handbuch

AIR-200 AIR MOUSE
REMOTE CONTROL WIRELESS
indicator
/
power
ir learning key
mic
/
play pause mouse on
up
/ /
ok enter
mouse left
left right
down
/ /
home return
menu
mouse right
page up
volume
page down volume
voice on
backspace
mute
compartment
USER MANUAL
Thank you for using the product of our company!
The AIR-200 is a wireless Air Mouse with built-in axis gyroscope and
gravity acceleration sensor and fidelity voice input. The Air Mouse performs
the functions of a traditional remote control, computer mouse, and gaming
motion controller. The plug and play USB receiver is compatible with personal
computer, projector, TV box, Home Theater Personal Computer, etc.
Holding the air mouse and rotating your wrist is converted into a movement
of a cursor across the screen and it allows you to control your computer,
projector and other entertainment equipment from a distance.
Ergonomics of air mouse will replace stationary computer mouse and infra-
red button remote control giving you convenience to manage your computer
and television set from a position which is most comfortable with you.
IR LEARNING
( take the example of learning „power" button)
The aim is to provide the AIR-200 with the IR code for the
on / off switch on the remote control of your player.
1. Press and hold the "power" button on the AIR-200
until the LED flashes slowly. The Air Mouse is now
in IR learning mode.
2. Hold the remote control of your player with the IR
LED frontally against the AIR-200 and press the power
/
button on the remote control of the player. The LED
off
lights up when the code has been recognized.
3. When the LED flashes slowly again, the Air Mouse has
completed the learning process.
4. The information is saved automatically.
5. To delete the code, press "OK" and "DEL" on the Air Mouse.
AIR MOUSE HAS 3 LEVELS OF CURSOR SPEED
+
From slow to fast:
-
/ Press and hold "OK" and "Volume +" buttons.
off
The speed adjusts one level when LED lights on.
From fast to slow:
Press and hold "OK" and "Volume -" buttons.
The speed adjusts one level when LED lights on.
battery
If the mouse pointer is not visible, please press the "
cover
move the remote control and check whether the pointer appears.
If this is not the case, please repeat - only press once (1x).
Function Keys:
Home: Press and hold 3 seconds to go back to the Home Screen;
Return: Go back to the previous screen;
OK: Confirm action or insert cursor;
Cursor Locking: Press to lock the air mouse, press again to unlock;
Play/Pause: Multimedia play/pause.
Voice Input:
In order to be able to use voice input, it is necessary to install the
"Google Assistant" app from the Google Play Store. Follow the instructions
of the "Google Assistant". Additional apps may be necessary.
Press and hold the "voice input" button to turn on voice channel.
Release the key to turn off voice channel.
Low battery reminder:
The red light flashes slowly when the AAA battery power
of the product is lower than 2V.
It means that the battery needs to be replaced at this time.
SENSOR CALIBRATION
Automatic calibration:
The changes of voltage and temperature may make the cursor drift.
In this case, put the mouse flat on the desk and remain still.
You can completely calibration by pressing any key to wake it up
when it is in hibernation mode.
HOW TO USE
For initial use plug an USB receiver into the USB port of your device and wait
for 20-60 seconds to install driver of USB receiver. Move the mouse.
If the mouse cursor moves on the screen, the pairing was successful.
If it was unsuccessful, press and hold "OK" and "Home" buttons until the LED
light begins to flash. Pairing is successful when the LED light stops flashing.
PRODUCT SPECIFICATIONS
Transmission method
Sensors
Number of keys
Range
Battery type
Material
Size
" button once (1x),
Weight
Note:
1. Remove the USB receiver from the battery compartment and plug it
into the USB port of your device (PC, TV, etc.).
With FANTEC media players typically in the USB 2.0 port.
2. Reinstall the battery if there is a red light always lighting.
3. IR learning only for "power" key.
GERMANY ∙ SINCE 1999
FANTEC GmbH - Hamburg / Germany * made in China
Typing errors, errors and modifications are subjects to change.
2.4G RF wireless
6-axis gyroscope
17
>10 meter
AAA * 2
ABS plastic and silicone
143 * 45 * 29mm
50g
