LED lighting console
Item no. 591312
3-Channel
Item no. 591487
4-Channel
Item no. 591294
6-Channel
Intended use
This product is used to generate lighting effects on dance floors, in party rooms etc. With a tongue and groove joint,
the individual elements can be arranged in a variety of shapes. It is approved only for connection to a standard
wall socket. Do not use other power supplies. It must only be used in enclosed spaces and therefore not outside.
Contact with moisture, e.g. in bathrooms, must be avoided under all circumstances. An external power supply unit
(for 100 - 240 V/AC, 50/60 Hz) provides the power supply.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If you use the product for
purposes other than those described above, the product may be damaged. In addition, improper use can cause
hazards such as short circuiting, fire, electric shock etc. Read the instructions carefully and keep them. Make this
product available to third parties only together with its operating instructions.
Delivery content
• LED lighting console
• Power supply unit
• Operating instructions
Safety instructions
Read the operating instructions carefully and especially observe the safety information. If you
do not follow the safety instructions and information on proper handling in this manual, we
assume no liability for any resulting personal injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) Persons / Product
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high humidity, moisture,
flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and protect it from any
accidental use. Safe operation can no longer be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height can damage the
product.
• The illuminant and housing of the device will get very hot during operation. Do not touch elements
including an illuminant during or shortly after operation.
• Ensure proper ventilation of the product. Do not cover it during operation. There is a danger of fire.
• Before rearranging elements of the lighting console, turn the device off and let it cool off for half an
hour. Disconnect the mains plug from the wall socket.
• When rearranging the elements handle them only by touching the housing. Do not apply pressure
on the illuminants.
• After replacement, wipe the new illuminant clean using a clean, dry cloth.
• Position the product in such a manner that it cannot fall down.
• Always arrange the elements of the product in such a way that they form a robust structure.
• Objects that are illuminated must be at least 0.5 m from the light source of the device. Easily
flammable materials such as decorative fabrics must have at least a distance of 0.5 m from the
device. Otherwise there may be a fire hazard!
• Never look directly or with optical instruments into the light beam.
• Point the light beam in such a way that it is directed below eye level.
• Attention, LED light:
- Do not look directly into the LED light!
- Do not look into the beam directly or with optical instruments!
• Never pour any liquids over electrical devices or put objects filled with liquid right next to the device.
If liquid or an object enters the interior of the device nevertheless, first power down the respective
socket (e.g. switch off circuit breaker) and then pull the mains plug from the mains socket. Do not
operate the product anymore afterwards, but take it to a specialist workshop.
• Never use the product immediately after it has been brought from a cold room into a warm one.
The condensation generated could destroy the product. The plug-in power supply unit also involves
danger to life by electric shock! Allow the product to reach room temperature before connecting it to
the power supply and putting it to use. This may take several hours.
• If the wall plug transformer is damaged, do not touch it; there is danger to life from electric shock!
First, switch off the mains voltage to the mains socket to which the wall plug transformer is connected
(switch off at the corresponding circuit breaker or remove the safety fuse, then switch off at the
corresponding RCD protective switch, so that all poles of the mains socket are disconnected). You
can then unplug the wall plug transformer from the mains socket. Dispose of the faulty wall plug
transformer in an environmentally friendly way; do not use it any more. Replace it with a wall plug
transformer of the same design.
• The mains outlet must be located near to the device and be easily accessible.
• As power supply, only use the supplied mains adapter.
• Only connect the power adapter to a normal mains socket connected to the public supply. Before
plugging in the power adapter, check whether the voltage stated on the power adapter complies with
Version 10/15
the voltage of your electricity supplier.
• Never connect or disconnect power adapters if your hands are wet.
• Never unplug the power adapter from the mains socket by pulling on the cable; always use the grips
on the plug.
• When setting up the product, make sure that the cable is not pinched, kinked or damaged by sharp
edges.
• Always lay the cables so that nobody can trip over or become entangled in them. This poses a risk
of injury.
• For safety reasons, disconnect the power adapter from the mains socket during storms.
b) Miscellaneous
• Consult an expert when in doubt about operation, safety or connection of the device.
• Maintenance, modifications and repairs are to be performed exclusively by an expert or at a qualified
shop.
• If you have questions which remain unanswered by these operating instructions, contact our
technical support service or other technical personnel.
Setup
1. Arrange the effect beamer by sliding the elements carefully onto each other. Make sure that the tongue and
groove fit properly into each other.
2. Also ensure that the effect beamer is always assembled as a robust and steady structure.
3. Place the effect beamer onto an even, clean surface.
Initial operation
1. Plug the cylindrical connector on the power cord into the power jack at the back of the control unit.
2. Connect the mains plug to a standard wall socket.
3. Turn the "Music" control dial and the "Speed" control dial counterclockwise as far as they will go.
4. Turn the effect beamer on using the on / off switch.
5. To use the effect beamer as a chaser light, turn the "Speed" control dial clockwise until the required speed
is set.
6. To use the effect beamer for music synchronisation, additionally turn the "Music" control dial clockwise and set
the required microphone sensitivity.
7. After use, turn the effect beamer off using the on / off switch.
8. If you will not use the product for a longer period of time, unplug the mains plug from the wall socket.
Cleaning
• Disconnect the product from the power supply before cleaning and let it cool down to room temperature.
• Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these could damage the casing
or even impair the functioning of the product.
• Do not immerse the product in water or other liquids.
• A dry and lint-free cloth and a brush can be used to clean the product.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product according to the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
Technical data
Operating voltage:
Current consumption:
Number of modules:
Module colours:
Number of LED
per modules:
Operating temperature:
Dimensions
(W x H x D):
Weight:
Power supply unit
Input voltage / current ...................................... 100 – 240 V/AC, 50/60 Hz, 200 mA
Output voltage / current ................................... 14 V/DC, 300 mA
Item no. 591312
Item no. 591487
14 V/DC
180 mA
3
4
1 x red, 1 x blue,
1 x red, 1 x blue,
1 x yellow
1 x yellow, 1 x green
36
-10 to +45 ºC
123 x 488 x 139 mm
348 x 265 x 129 mm
Approx. 1 kg
Approx. 1.16 kg
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau
(www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming,
or the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited. This publication represent the technical status at the time of
printing.
© Copyright 2015 by Conrad Electronic SE.
