BN 2134127
ATmega32u4 Development Board
EN Quick Instructions
Version: 1
Electrostatic discharge (ESD)
Electrostatic discharge (ESD) can destroy your components.
Before you touch components, remove any electric charge from
your body by touching a grounded object (e.g. a water pipe).
Delivery Content
Board
l
Description
The Leonardo Board is a simple to operate and freely programmable
developer board for the Arduino® platform.
Flashing
To flash the board with new programs, connect the board to your com-
puter (that holds the program) via the microUSB connector. As soon
as the board receives power, the LED ON lights up.
Programming
A simple way to program the board is through the Arduino® IDE. You
can download it from http://www.arduino.cc.
Use a microUSB cable to connect the board to your computer running
the Arduino® IDE.
When you start the IDE, select the Arduino Leonardo board and
corresponding port as the interface.
Quick test
For a quick test, flash the board with the Blink example sketch avail-
able in the IDE under File > Examples > 01.Basics > Blink.
Save the sketch and upload it to the board through the chosen inter-
face. Once uploading is completed, the LED labelled L on the board
flashes according to the settings in the code example.
