3) If the light cover or the lighting unit (with the timer) need re-
placing, disassemble the two elements by unscrewing the three
screws which keep them together using a suitable Phillips
screwdriver (fig. 26).
4) Clean the lighting unit with a damp cloth.
5) Reassemble and reposition the components carefully repeating
the above described procedure in opposite order.

7. TROuBlEShOOTINg

PROBlEM
Missing connection of
the led driver to the pow-
er outlet
The lighting
Missing connection of
is not
the lighting unit to the led
working
driver
Other
The thermal heater is not
plugged into its power
outlet
The thermal heater ad-
Water
justment knob is set too
temperature
low
low
The ambient temperature
is too low
Other
The pump is not plugged
into its power outlet
No water
The pump is jammed
flow
Other
The intake tube, pump,
Low water
delivery tube or delivery
flow
is clogged
24
Downloaded from www.Manualslib.com
CAuSE SOluTION
Connect the led driver
to the power outlet
Connect the lighting
unit to the led driver
with its connector
Contact your retailer
Plug the
heater into its power
outlet
Set the temperature
to the correct value
(par. 5.1.3)
Add a supplementary
thermal heater
Contact your retailer
Plug the pump into its
power outlet
Clean the impeller
(par. 6.3)
Contact your retailer
Clean the parts
25
manuals search engine
EN

8. STORAgE ANd REPACkINg

To store the product:
1) Carefully clean and dry off all parts of the product. The mechan-
ical filtration sponges and the 3ACTION cartridges must be dis-
posed of according to local regulations.
2) Store the product and its components in suitable containers.
3) keep the product indoors in a dry place, out of the weather and
freezing temperatures.

9. OPTIONAl MOdulES ANd SPARE PARTS

9.1. Optional modules
The product can be fitted with the following optional modules (not
included):
Module
ROBOFOOD
programmable fish
feeder
thermal Askoll CO PRO-
2
gREEN SYSTEM
CO2 enricher
ASkOLL
ROBOFORMULA
PURE aquarium
stand
Description
Battery powered programmable fish feeder
which can dispense up to two meals a day
Dispenses CO into the aquarium to pro-
2
mote plant growth
Electronic aquarium treatment dispenser
with Askoll Formula Azure cartridge for
clear water and healthy plants
Specifically designed, it is the best fitting
for the aquarium, enhancing its style and
providing a sturdy and suitable support to
the same
