Lcd-Display; Remote Control - Power Dynamics AV-150BT Bedienungsanleitung

LCD DISPLAY
1. Selected mode - The word FOLDER will be flashing on the screen in FOLDER mode. When a REPEAT mode is
selected, the display will show ALL, NORMAL, SINGLE, FOLDER, RANDOM or BROWSE, depending on the chosen
mode. BT will appear in the BT mode. The display will show FM in FM mode.
2. Source name - The display will show U in USB mode, the display will show S when SD mode is chosen. Press the
mode button to switch from one input to the other.
3. Track number - Displays the number of current playing track.
4. Name -
Displays the file name of the current track.
Displays the folder name of the current folder in folder mode.
Displays connection status with the BT mode.
Displays the FM channel name and channel frequencies in FM mode.
Displays EQ name in the USB/SD mode.
Displays NO DISK when in USB/SD mode no USB or SD CARD is inserted.
5. Elapsed time - Displays the playing time of the current track in minutes;seconds.

REMOTE CONTROL

1. ON / OFF
Press this button to turn on/off the device.
2. CH- / CH+
Press these buttons to select the previous or next channel, when in FM mode.
3. PREVIOUS / NEXT
Presse these buttons to select the previous or next track, when in USB/SD or BT
mode.
4. VOLUME UP / DOWN
Press to alter the output volume of the device.
5. NUM PAD
Press the numbers to select tracks directly. The device takes 1-2 seconds to
respond.
6. REPEAT MODES
Press this button to select a repeat mode. Hold for 3 seconds to enter folder
searching.
7. MODE
Press this button to select a playing mode.
8. EQ
Press to use EQ function.
9. PLAY / PAUSE
Press to pause or (re)start play.
CONNECTING WITH BT
1.
2.
3.
If password is required, you can enter "0000".
Attention: The BT distance is approx. 10 meter without any barrier.
Activate the BT-function on your device (Mobile phone, tablet etc.) from which you want to play the
music. See the operating instructions for that device.
Press the "MODE" button and activate BT-function.
Select "AV-150BT" on your BT-device and make the BT-connection
5
