Operating instructions
Single LNB
Item no. 1362483
Intended use
The product is designed to be installed on the LNB bracket (Ø 40 mm) of a satellite
antenna and is used to receive the appropriate digital satellite signals (TV, radio).
Always observe the safety instructions and all other information included in these op-
erating instructions.
This product complies with the applicable national and European requirements. All
names of companies and products are the trademarks of the respective owners. All
rights reserved.
Package contents
• LNB
• Rubber bushing
• Operating instructions
Explanation of symbols
This symbol points to specifi c risks associated with handling, function or
operation.
The "arrow" symbol points to special tips and operating information.
Safety instructions
Damage due to not following these operating instructions will void the
warranty! We do not assume any liability for any resulting damage!
We do not assume any liability for material and personal damage caused
by improper use or non-compliance with the safety instructions. In such
cases, the warranty will be null and void.
• The unauthorised conversion and/or modifi cation of the product is not
permitted for safety and approval reasons (CE). Do not disassemble the
product.
• The product is not a toy and should be kept out of the reach of children.
• The product is designed for operation outdoors. Pay attention to the cor-
rect operating position during installation, however (connection must face
downwards).
• Pay attention to the safety instructions and the information about the in-
stallation that are mentioned with regard to your satellite antenna. The
same applies to connecting the cables/devices to the outlet of the LNB.
• During installation and connection, observe all of the necessary accident
prevention regulations for e.g., when you use a ladder to install the LNB to
a satellite antenna. Use only suitable tools for the installation and connec-
tion.
In case of doubt, leave the installation and connection work to a special-
ist!
• Do not leave packaging material carelessly lying around, since it could
become a dangerous plaything for children.
• Handle the product with care; it can be damaged by impacts, blows, or
accidental falls, even from a low height.
Assembly
Attention, important!
If you do not have the expertise to install the device correctly, please con-
tact an expert or a specialist workshop and let them carry it out!
A suitable measuring device is necessary for the optimal setting of a satel-
lite antenna with the LNB for digital TV/radio reception installed inside.
Install the LNB to the appropriate bracket (feed reception) of your satellite antenna.
The bracket must accordingly have an opening diameter of 40 mm.
The round side of the LNB must point towards the satellite antenna. Furthermore,
make sure that the LNB connectors point down.
There is a degree indicator on the side of the LNB. The LNB is to be rotated
depending on your location and the satellite you would like to receive.
Connection
First slide the provided rubber bushing over the end of the cable with F plug, which
is to be connected to the LNB. Pay attention to the correct position (the side with the
notch in the rubber bushing must point in the direction of the LNB).
Connect the outlet of the single LNB with the input of your satellite receiver via a suit-
able antenna cable and corresponding F plug.
It is not possible to operate the single LNB in connection with a multi-switch.
It is absolutely necessary to use a high-quality, doubly shielded antenna ca-
ble suitable for satellite signals so that the signals of the LNB are optimally
routed.
If the cable between the LNB and the satellite receiver is very long, make
sure that the cable has a low damping.
The F plug that is used to connect to the LNB must be suitable for operating
outdoors so that no moisture can penetrate.
Slide the rubber bushing in the direction of the LNB so that it clicks into place and is
seated fi rmly. The rubber bushing gives the F plug/LNB connection extra protection
against precipitation.
Disposal
The product must not be disposed of in the household waste.
Please dispose of the product at the end of its service life according to the
current statutory requirements.
Technical data
Power supply ...................................... via SAT receiver
Operating voltage............................... 13 - 19 V/DC
Power consumption........................... max. 80 mA
Frequency range (Inlet)..................... Low band: 10.7 - 11.7 GHz
...............................................................
Frequency range (Outlet) .................. Low band: 950 - 1950 MHz
...............................................................
LO frequency....................................... Low band: 9.75 GHz
...............................................................
Band control ....................................... Low band: 0 kHz
...............................................................
Polarity switching .............................. V = 11.5 - 14 V/DC
...............................................................
Construction type ............................... Single LNB
Outlets .................................................. 1
Impedance .......................................... 75 Ω
Amplifi cation ....................................... 55 dB (typical)
Noise factor ........................................ 0.4 dB (typical)
Feed receiver ...................................... Ø 40 mm
Dimensions (L x W x H) ..................... 108 x 53 x 53 mm
Weight .................................................. approx. 101 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfi lming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent
the technical status at the time of printing.
© Copyright 2015 by Conrad Electronic SE.
High band: 11.7 - 12.75 GHz
High band: 1100 - 2150 MHz
High band: 10.6 GHz
High band: 22 kHz
H = 16 - 20 V/DC
