Operating instructions
CR36e-USB-C card reader, black
Item no. 1405810
Intended use
The product can be plugged into a computer's USB port and it is designed for reading and
writing to appropriate memory cards.
Always observe the safety instructions and all other information included in these operating
instructions.
This product complies with the legal national and European requirements. All names of compa-
nies and products are the trademarks of the respective owners. All rights reserved.
Package Content
• Card Reader
• Operating instructions
Up-to-date operating instructions
Download the latest operating instructions via the link www.conrad.com/downloads or scan the
QR code. Follow the instructions on the website.
Explanation of Symbols
This symbol indicates specific risks associated with handling, operation or use.
The arrow symbol indicates special tips and operating information.
Safety Instructions
Damage due to failure to follow these operating instructions will void the
warranty/guarantee! We assume no liability for subsequent damages!
We do not assume any liability for material and personal damage caused by
improper use or non-compliance with the safety instructions. The warranty/
guarantee will be void in such cases.
• The unauthorised conversion and/or modification of the product is not permitted
for safety and approval reasons (EC). Do not open/disassemble!
• The product should be used only in dry indoor areas; it must not get wet or damp.
• The product is not a toy and should be kept out of the reach of children.
• Do not leave the packaging material unattended since this may become a dange-
rous plaything for children.
• Handle the product with care; it can be damaged by impacts, blows, or accidental
falls, even from a low height.
Getting Started, Connection
Connect the card reader with one of your computer's USB port (the C-USB plug will fit in either
orientation). The computer does not need to be switched off.
The operating system of your computer will detect the new hardware, and automatically install
the required drivers; they are already present in the operating system.
If no memory card is inserted, the small rectangular frame will light up red on the top of the card
reader. When a memory card is inserted, a blue LED is additional activated internally, so that
the frame will light up purple. In case of read/write accesses, the frame will flash alternating
between red and purple.
Inserting/Removing the Memory Card
The card reader has in total 8 slots.
The two directly superposed slots for SD and microSD memory cards are directly
connected internally and cannot be used simultaneously.
Insert a memory card into the appropriate slot in the card reader (as printed on the card reader).
Pay attention to the correct orientation when inserting the memory card; do not use force!
If you wish to remove the memory card from the card reader (or to disconnect the card reader
from the computer), wait until all read/write accesses to the memory card are completed. Only
then you should remove the memory card from the card reader.
If the memory card is removed during read/write access (or the card reader is dis-
connected from the computer), the data on the memory card can be damaged. The
memory card may possibly even require subsequent re-formatting.
Reading from/writing to memory cards
A memory card inserted into the card reader will be integrated in the same way as a conven-
tional removable media drive. For example, with the Windows File Manager you can now read
the data on the memory card (or store data on the memory card) in the same way as you use
a USB hard drive or a USB stick.
The maximum speed attained when reading/writing a memory card depends on your memory
card; in addition, the speed is limited by the USB2.0 transfer.
Reminder! When writing on SD/SDHC/SDXC storage media, make sure that write
protection is switched off (small sliding switch on the side of the memory card).
Tips for SDXC memory cards
In order to use SDXC memory cards with Windows XP, an update of Windows XP is required.
Only then will the "exFAT" file system of SDXC memory cards be supported.
You can download the update at www.microsoft.com. To find the update, enter the search
terms, e.g., "exfat windows xp" in the search bar of your Internet browser.
With Windows Vista you have to have Service Pack 1 installed in order for the card reader to
support SDXC cards.
Newer versions of windows directly support the "exFAT" file system of SDXC memory cards
(e.g., Windows 7 or higher).
Maintenance and cleaning
The product is maintenance-free. Repair or maintenance work must be carried out by a special-
ist or a specialist shop.
You can use a clean, dry, soft cloth for cleaning. Dust can be very easily removed with a soft,
clean brush and a vacuum cleaner.
Do not use aggressive chemical or scouring cleaning agents, as this may lead to discolouration
or changes in the material on the surface.
Disposal
The product must not be disposed of with the household waste.
Dispose of the product at the end of its serviceable life in accordance with the cur-
rent statutory requirements; e.g., return it to any suitable collection point.
Technical Data
Operating voltage ......................... 5 V/DC via USB
USB standard ............................... USB2.0 (USB1.1 compatible)
Connector plug ............................. USB-C
Suitable memory cards ................. SD/SDHC/SDXC, microSD/microSDHC/microSDXC, MMC,
MSHG, CF, M2, xD
Operating conditions ..................... Temperature from 0 °C to +60 °C, air humidity: from 20%
to 80% relative, non-condensing
Dimensions (L x W x H) ................ 74.8 x 48 x 15 mm
Weight .......................................... 33 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
© Copyright 2016 by Conrad Electronic SE. 1405810_V2_0716_02_VTP_m_EN
