Operating instructions
Modular 24 port keystone patch panel
Item no. 1691749
Intended Use
The product is suitable for installation in a 48.26 cm (19") network cabinet. Up to
24 keystone modules can be installed in the product.
For safety purposes, you must not rebuild and/or modify this product. Using the
product for purposes other than those described above may damage the product.
In addition, improper use can cause hazards such as a short circuit, fire or electric
shock. Read the instructions carefully and store them in a safe place. Only make this
product available to third parties together with its operating instructions.
This product complies with statutory, national and European regulations. All company
and product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Patch panel
• 4x screws (M6 x 18 mm)
• 4x cage nuts
• 4x plastic washers
• 24x cable ties (75 x 1.9 mm)
• Hook-and-loop tape (150 x 10 mm)
• Operating instructions
Up-to-date operating instructions
Download the latest operating instructions at www.conrad.com/downloads or scan
the QR code shown. Follow the instructions on the website.
Explanation of symbols
The symbol with an exclamation mark in a triangle is used to highlight
important information in these operating instructions. Always read this
information carefully.
Safety instructions
Read the operating instructions and safety information carefully. If
you do not follow the safety information and information on proper
handling in these operating instructions, we will assume no liability
for any resulting personal injury or damage to property. Such cases
will invalidate the warranty/guarantee.
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. It may become
a dangerous toy for children.
• Protect the product from extreme temperatures, direct sunlight, strong
jolts, high humidity, moisture, flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of
operation and protect it from any accidental use. Safe operation can no
longer be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a
low height may damage the product.
• Always observe the safety information and operating instructions of any
other devices which are connected to the product.
• Consult a technician if you are not sure how to use or connect the
product, or if you have concerns about safety.
• Maintenance, modifications and repairs must be done by a technician or
a specialist repair centre.
• If you have questions which remain unanswered by these operating
instructions, contact our technical support service or other technical
personnel.
Installation
• Press lightly on the locking clip of the black module carrier. Pull the module carrier
out of the patch panel.
• Insert a keystone module in the module carrier.
• Insert the module carrier back into the patch panel. The locking clip must thereby
engage.
• Secure the cable of the keystone module with a cable tie or the hook-and-loop
tape.
• Insert the patch panel in the network cabinet. Fix the patch panel with the supplied
installation material.
• Attach the ground cable to a suitable ground connection.
Care and Cleaning
• Never use aggressive detergents, rubbing alcohol or other chemical solutions, as
these could damage the housing or stop the product from functioning properly.
• Use a dry, lint-free cloth to clean the product.
Disposal
The product must not be disposed of with the household waste. At the end
of its service life, dispose of the product according to the relevant statutory
regulations.
Technical data
Material ..........................................SPCC, 1.5 mm thick
Operating conditions ......................-40 to +80 ºC, 10 – 85 % RH
Storage conditions .........................-40 to +85 °C, 10 – 85 % RH
Dimensions (W x H x D) ................482.6 x 44.45 x 140 mm
Weight ...........................................793 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in
electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE.
*1691749_v1_0818_02_IPL_m_en
