Functions & Controls - Esx V450.2 Bedienungsanleitung

2-Channel Amplifier - Functions & Controls
CROSSOVER OFF / LP / HP
Position HP - Highpass is activated, the frequency of the speakers is bounded below.
The threshold is from 40Hz to 400Hz adjustable via FREQ ADJUST.
Position LP - Lowpass is activated, the frequency of the speakers is bounded above.
The threshold is from 40Hz to 400Hz adjustable via FREQ ADJUST.
Position OFF - full range output signal.
STATUS - LED
The LED lights up blue the
amplifier is in operation-mode.
BASS BOOST
Allows to adjust the bass boost from
-18dB - +18dB at 45Hz.
V 450.2
INPUT GAIN
Allows to adjust input level from the
head unit.
REMOTE BASS PORT
Allows to control Bass Boost via Remote Conrol from
any location, e.g. from driver's seat. Please connect the
included bass remote here.
18
LINE INPUT
Allows to connect the amplifier
with the head unit via RCA cable.
