SETTING MENU LED DISPLAY:
Main Level
A001
D001
SLAV
Cf01
Cj01
Cp01
Ct01
RGB
DENO
SOUD
DMX CHANNEL CHART: SEE END OF THE MANUAL
FIXTURE CLEANING
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize
light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or
particularly dirty surrounding can cause greater accumulation of dirt on the unit's optics.
⠗ Clean with soft cloth using normal glass cleaning fluid.
⠗ Always dry the parts carefully.
⠗ Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

SPECIFICATIONS

Supply Voltage: .............................................................................................................. 220-240V~ 50/60Hz
Consumption: .......................................................................................................................................... 20W
Light source: ...................................................................................................................... 18 x 1W LED RGB
Operating modes .......................................................................DMX, Auto-run, Sound Control, Master-slave
Dimensions: ................................................................................................................... 180 x 180 x 100mm
Weight: ................................................................................................................................................ 0.63kg
IMPORTANT NOTE:
Ask your local authorities or your dealer about the way to proceed.
4
Programming Levels
A001-511
D001-511
Cf01-99
Cj01-99
Cp01-99
Ct01-99
R000-255 (red)
G000-255 (green)
B000-255 (blue)
Electric products must not be put into household waste. Please bring them to a recycling centre.
Description
7 channel DMX mode
4 Channel DMX mode
Slave mode
Fade mode 1 (slower)
Skip mode
Fade mode 2 (faster)
Strobe mode
Custom static colors
Color combination
Auto mode
Sound activated
EN
