Technical Features - Intesis Ac Cloud Control Installationsanleitung

Enclosure
Dimensions
Weight
Colour
Power supply
Radio Parameters
LED indicators
Button
Temperature sensor
Infrared communication
Binary Input
Operating Temperature
Operating humidity
Stock humidity
RoHS conformity
54

Technical Features

ABS (V-0, 5VB). 2,1 mm thickness
PC (V-2). 1 mm thickness
81 x 78 x 28 mm
76 g
White
5VDC 0,25 A NEC Class 2 or Limited Power Source (LPS) and
SELV rated Power supply
Wi-Fi 802.11 (b/g/n)
RF Frequency range: 2412 to 2497 MHz
Output power (average): 8 dBm
(Modulated signal at antenna port; 11Mb/Sec.)
1 x Device status
1 x Push button
1 x Internal temperature sensor
1 x Infrared receiver
2 x Infrared emitter
1 x Minijack connection (3.5mm stereo jack)
From 0ºC to 40ºC
<93% HR, no condensation
<93% HR, no condensation
Compliant with RoHS directive (2011/65/EU)
