Goobay 49645 Betriebsanleitung Seite 2

EN
User Manual
USB Mini hand fan with stand function
1 Safety instructions
1.1 In general
• Read the user manual completely and carefully before use.
The user manual is part of the product and contains important information for correct use.
• Keep this user manual.
The user manual must be available for uncertainties and passing the product.
• Do not open the housing.
• NEVER leave unattended while in operation!
• Installation, assembly, maintenance and repair work must be carried out only by trained
electrical specialists.
• Compare the specifications of product, power supply and peripherals. These must be
identical.
Not meant for children.The product is not a toy!
• Do not repair defective products yourself, but contact the dealer or the manufacturer.
• Do not modify product and accessories.
• Avoid stresses such as heat and cold, moisture and direct sunlight, microwaves, vibra-
tions and mechanical pressure.
• Only use in dry ambience.
• Risk of injury by stumbling and falling
• Keep limbs and objects away from rotating parts.
• Rotating parts can pull loose clothing and hair.
• Do not operate in an explosive environment.
• Do not cover the product.
Battery hazards
The batterie (rechargeable) is replaceable.
• Do not deform, burn or disassemble the battery.
Batteries and rechargeable batteries may be damaged and leak if not used for the inten-
ded purpose.
• Do not short-circuit the battery or immerse it in liquids.
There is a danger of: Explosion, fire, heat, smoke and/or gas.
• Do not expose the battery to heat, such as sunlight or heat from heating, or fire
Extreme heat can lead to explosion and/or leakage of corrosive liquid.
Mechanical damage can cause gaseous substances to escape, which can be highly irrita-
ting, flammable or toxic.
2 Description and Function
2.1 USB Mini hand fan with stand function
This product is a USB fan for the desk.
• very quiet electric motor with low power consumption
• rechargeable battery
• easy charging via USB cable
2.2 Operating elements and parts
Fig. 2: USB Ventilator
1 ON/OFF button
3 Rotor
5 Strap
2.3 Scope of delivery
USB-Ventilator, USB adapter cable, strap, stand, user manual
3 Intended Use
We do not permit using the device in other ways like described in chapter „Descrip-
tion and Function" or in the „Safety Instructions". Use the product only in dry interi-
or rooms. Not attending to these regulations and safety instructions might cause
fatal accidents, injuries, and damages to persons and property
4 Connecting and Operating
4.1 Preparation
• Check the scope of delivery for completeness and integrity.
• Only use the supplied Micro USB charging cable.
4.2 Charging
The battery must be fully charged before initial operation.
1. Plug the Micro USB connector (6) of the supplied charging cable into the Micro USB
socket (2) of the fan.
2. Connect the USB 2.0 connector of the adapter cable (6) to a USB power source. This
can be either a 230 V USB charging adapter or the USB socket of a PC. The charging sta-
tus indicator flashes red. The fan is fully charged when the charging status indicator is red.
3. After charging is complete, disconnect the USB adapter cable (6) from the fan and the
USB power source.
4.3 Operating and adjusting the blower intensity
Briefly press the ON/OFF button to turn on the fan. The fan power can be adjusted by
repeatedly pressing the button in 3 steps:
Light = 1x short Strong = 2x short
To stop the fan, press the button briefly 4 times.
4.4 Replacement battery
Open the rear protective cap (see picture) and carefully remove the
battery. Then insert the new battery with the correct polarity. Finally,
put the protective cap back on.
REV2020-05-06
V1.1 ir
Subject to change without notice
2 Micro USB socket
4 Stand
6 USB adapter cable
Turbo = 3x short OFF = 4x short
4.5 Mounting loop
Guide the black ribbon around the lower
opening of the fan (see picture).
5 Specifications
Connections
Input
Power
Dimensions
Weight
Type
Voltage
Capacity
Energy
Charging time
Weight
USB adapter cable
Connections
Cable length
Weight
Tab. 2: Specifications
6 Maintenance, Care, Storage and Transport-
ation
The product is maintenance-free.
• Only use a dry and soft cloth for cleaning.
• Do not use cleaning agents and chemicals.
• Store cool and dry.
• Store the product out the reach of children and in a dry and dust-protected ambience
when not in use.
• Keep and use the original packaging for transport.
7 Disposal Notes
7.1 Product
According to the European WEEE directive, electrical and electronic equip-
ment must not be disposed with consumers waste. Its components must be
recycled or disposed apart from each other. Otherwise contaminative and
hazardous substances can damage the health and pollute the environment.
As a consumer, you are committed by law to dispose electrical and electronic devices to
the producer, the dealer, or public collecting points at the end of the devices lifetime for
free. Particulars are regulated in national right. The symbol on the product, in the user
manual, or at the packaging alludes to these terms. With this kind of waste separation,
application, and waste disposal of used devices you achieve an important share to envi-
ronmental protection.
WEEE No: 82898622
7.2 Batteries / rechargeable batteries
(Rechargeable) batteries must not be disposed of with household waste. Their
components have to be supplied separately to the recycling or disposal,
because toxic and dangerous ingredients can harm the environment if not
disposed of sustainably. As a consumer, you are obliged to return them at the
end of their service lives to the manufacturer, the sales outlet or established for
this purpose, public collection points for free. Details regulates the respective country's
law. The symbol on the product, the instruction manual and / or the packaging draws
attention to those provisions. With this kind of material separation, recovery and disposal
of waste (rechargeable) batteries you make an important contribution to protecting our
environment. D-34000-1998-0099
7.3 Packaging
Packaging can be disposed of free of charge at the suitable collection points
– paper belongs in paper bins, plastics belong in yellow sacks and glass bel-
ongs in used glass bins. DE4535302615620-V
8 EU Declaration of Conformity
With the CE sign Goobay , a registered trademark of the Wentronic GmbH,
ensures that the product is conformed to the basic European standards and
directives.
- 2 -
USB Ventilator
USB Micro socket
5 V , 1 A
4.5 W
106 x 42 x 205 mm
123 g
Battery
18650 Lithium-Ion Battery
5 V
2000 mAh
7.5 Wh
3 hours
35 g
USB A connector,
USB B micro plug
~80 cm
15 g
by Wentronic GmbH | Pillmannstraße 12
38112 Braunschweig | Germany
49645
Goobay
®
