User Manual
Introduction
Thank you for purchasing the Fibre Optic Hybrid USB Type C Cable. This product has been designed to
provide trouble free, reliable operation. It benefits from both a LINDY 2-year warranty and free lifetime
technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
Lindy's Fibre Optic Hybrid USB Type C Cables are the professional solution for the transmission of video
signals over longer distances. Combining the flexibility and high EMI & RFI resistance of fibre optic cable
with standard copper cabling, these hybrid cables are ideal for use in critical AV setups or commercial
installations. Supplied as a thin cable with a premium metal, narrow USB Type C connector, this can be
installed easily through conduit and other narrow spaces with no damage caused to the internal cable
structure.
Package Contents
▪
Fibre Optic Hybrid USB Type C Cable
▪
This manual
Features
▪
USB Type C cable for video data only
▪
Supports resolutions up to 3840x2160@60Hz 4:4:4 10bit, 3840x2160@60Hz RGB 8bit
▪
Reduced EMI and RFI
▪
Supports HDCP 2.2
Specification
▪
Supported Bandwidth: 21.6Gbps
▪
Cable Type: Fibre Optic Hybrid (4 x 850nm OM3-15
▪
Minimum Bend Radius: 45mm (1.77in)
▪
Nominal Attenuation: -1dB~-2dB
▪
Jacket Diameter: 4.5mm (0.177in)
▪
Jacket Material: PVC
▪
Colour: Black
▪
Power Consumption: <250mW at each side of the installation
▪
Operating Temperature: 0°C - 50°C (32°F - 122°F)
▪
Storage Temperature: -20°C - 85°C (-4°F - 185°F)
0μm
MMF & 7 x Copper Wire)
English
