Technical data:

Model
Number of channels
Number of bodypacks
Frequency
Frequency Reproduction Range
Radio Frequency Sensitivity
Range max.
Display Receiver
Dimensions Receiver (W x H x D)
Weight Receiver
19" able
Handheld Transmitter Strength

Troubleshooting:

The following overview serves as an aid for quick troubleshooting. If you are unsure, contact the
manufacturer, the dealer or the corresponding specialist personnel. Never open the device on
your own!
Symptom
No function
No sound, but power LED lights
up
No wireless connection
If the specified corrections have not led to success, please contact our service staff. The contact
details can be found at www.musicstore.de
MSW Pro 4 Bodypack
4 channel
4 bodypacks
823 – 832
863-865 Mhz
50 Hz – 16 kHz (+/- 3 dB)
Input 6 dBμVS/N>80 dB
60 m
4x OLED
482 x 45 x 215 mm
2,0 Kg
Yes
10 mW
Troubleshooting
Check the network connection and the fuse
Check that the batteries are sufficiently charged
Check the cable connections at the inputs and
outputs
The jack or XLR cables may be defective. Please
replace them
Check whether the distance between transmitter
and receiver is too great or is
disturbed/interrupted by an object, for example.
